Replace The Power Supply - Spectra Logic Spectra T120 Power Supply Replacement Instructions

R
EPLACE THE
1. Use a #3 or #2 Phillips screwdriver to loosen the screw in the upper
2. Pull outward on the handle and gently remove the power supply from
3. Set the old power supply aside for return to Spectra Logic.
4. Place the new power supply into the empty slot and push it in gently.
5. Tighten the screw using a #3 or #2 Phillips screwdriver.
6. Reattach the power cord and flip the power switch to the "on" position.
7. If necessary, use your backup software to restart any backups that were
You are now ready to package the component for return to Spectra Logic.
July 2010
P S
OWER UPPLY
right corner of the power supply that you are removing.
Figure 1 The power supply screw.
the library.
Figure 2 Pulling out the power supply.
stopped when the power supply malfunctioned.

Replace the Power Supply

Remove screw
Power supply
handle
5
T120 Library
