Title: Work Instruction – ProJet 6000/7000 Manual Resin Stirring Procedure
Doc: 283584-00
Rev: A
Purpose: To provide step-by-step work instructions for manually stirring the vat in the ProJet 6000 and
7000 printers.
Tools & Supplies Required:
• Nitrile gloves
• Safety goggles
• Lab coat
• Absorbent paper towels
• 3/8" to 1/2" variable-speed drill (cord or cordless) which can operate to stir resin for at least 30
minutes.
• A propeller which has a long shaft stem and can be attached to the drill for mixing. The total length
of the propeller should not be longer than 6" (15cm).
3D SYSTEMS CONFIDENTIAL
Description: ProJet 6000 and 7000
Date: 9/11/14
Example propeller
Page: 1 of 7
Advertisement
Table of Contents
Related Manuals for 3D Systems ProJet 6000
Summary of Contents for 3D Systems ProJet 6000
- Page 1 Description: ProJet 6000 and 7000 Rev: A Date: 9/11/14 Page: 1 of 7 Purpose: To provide step-by-step work instructions for manually stirring the vat in the ProJet 6000 and 7000 printers. Tools & Supplies Required: • Nitrile gloves • Safety goggles •...
- Page 2 3D SYSTEMS CONFIDENTIAL Title: Work Instruction – ProJet 6000/7000 Manual Resin Stirring Procedure Doc: 283584-00 Description: ProJet 6000 and 7000 Rev: A Date: 9/11/14 Page: 2 of 7 • Open the machine door and remove the platform from the system (if it is in the system) •...
- Page 3 3D SYSTEMS CONFIDENTIAL Title: Work Instruction – ProJet 6000/7000 Manual Resin Stirring Procedure Doc: 283584-00 Description: ProJet 6000 and 7000 Rev: A Date: 9/11/14 Page: 3 of 7 • Go to the “Advanced” page, select “Print Applicator,” and select “Park.”...
- Page 4 3D SYSTEMS CONFIDENTIAL Title: Work Instruction – ProJet 6000/7000 Manual Resin Stirring Procedure Doc: 283584-00 Description: ProJet 6000 and 7000 Rev: A Date: 9/11/14 Page: 4 of 7 • Go to the “Advanced” screen and select “Elevator/Leveler.” • Select “Drain Print Tray.”...
- Page 5 3D SYSTEMS CONFIDENTIAL Title: Work Instruction – ProJet 6000/7000 Manual Resin Stirring Procedure Doc: 283584-00 Description: ProJet 6000 and 7000 Rev: A Date: 9/11/14 Page: 5 of 7 • Put the propeller at the stirring position. The stem should form a 45-60° angle with the horizontal plane.
- Page 6 3D SYSTEMS CONFIDENTIAL Title: Work Instruction – ProJet 6000/7000 Manual Resin Stirring Procedure Doc: 283584-00 Description: ProJet 6000 and 7000 Rev: A Date: 9/11/14 Page: 6 of 7 • Close the machine door. • When alerted, select “Yes” to turn the power back on.
- Page 7 3D SYSTEMS CONFIDENTIAL Title: Work Instruction – ProJet 6000/7000 Manual Resin Stirring Procedure Doc: 283584-00 Description: ProJet 6000 and 7000 Rev: A Date: 9/11/14 Page: 7 of 7 • To clean the drill and propeller, take them to a room away from the machine and wipe down with isopropyl alcohol and paper towels.
