Stirring The Resin - 3D Systems ProJet 6000 Work Instruction

Title: Work Instruction – ProJet 6000/7000 Manual Resin Stirring Procedure
Doc: 283584-00
Rev: A
• Put the propeller at the stirring position. The stem should form a 45-60° angle with the
horizontal plane.
7
• The propeller should be submerged at the center of the print tray.
• Turn on the drill and slowly increase the rpm until it reaches the highest rpm without the
resin overflowing.
• Stir the resin for about 30 minutes.
• During the stirring procedure, debris may collect around the propeller or show up on the
resin surface. If this occurs, stop stirring and remove the debris.
8
• When you have finished stirring, remove the drill and place the drill and propeller in an
appropriate location, supporting them with absorbent paper towels to avoid spilling excess
resin on any surfaces.
3D SYSTEMS CONFIDENTIAL
Description: ProJet 6000 and 7000
Date: 9/11/14
Drill with propeller submerged in the
resin at the proper angle for stirring
Page: 5 of 7
