- Page 1 From Eye to Insight CaptiView User Manual 10 746 768 - Version 01...
- Page 2 In developing our systems, we have placed great emphasis on simple, self- explanatory operation. Nevertheless, we suggest studying this user manual in detail so that you know and are able to utilize all the benefits of your Leica surgical microscope in an optimum way.
-
Page 3: Table Of Contents
Checking the wiring on the Leica OH6 / OHX Operation Operation of the instrument with handles for Leica M530 OH6 / OHX Operating the CaptiView on the control unit of the Leica M530 OH6 / OHX Settings for CaptiView Application 1 – FL800 Application 2 – IGS Application 3 –... -
Page 4: Introduction
Product identification The model code and serial numbers of your product are located on the identification label on the CaptiView. Enter this data in your user manual and always refer to it when you contact us or the service workshop regarding any questions you may have. -
Page 5: Safety Notes
It is the responsibility of the user to ensure that the limits of the above-mentioned standards are not exceeded. If in • The CaptiView module is an optical instrument you can use to doubt, please contact the appropriate technical department or superimpose data or images. -
Page 6: Design And Function
Design and function Design and function CaptiView controls 1 Emergency stop switch Design and function of the handles for Leica M530 OH6 / OHX 1 Joystick for menu navigation in the CaptiView CaptiView / Ref. 10 746 768 / Version 01... -
Page 7: Wiring
XGA in General input (e.g. Endoscopic camera) following connections: IGS Connector XGA 3 Note: FL800 connected internally XGA 2 FL800 XGA 1 General input (e.g. Endoscopic camera) XGA Out To the CaptiView CaptiView / Ref. 10 746 768 / Version 01... -
Page 8: Operation
Leica M530 OH6 / 5.2.1 Operating the control unit If you are using a CaptiView, a "DIC" Quick Access Button is added to the static menu line. 1 Mag up / down 2 Joystick (optionally for XY movements or for menu navigation in... - Page 9 Opens or closes the shutter manually as pre-configured in the user settings. • "DIC: Brightness +" Increases the brightness of the superimposed data. • "DIC: Brightness –" Decreases the brightness of the superimposed data. CaptiView / Ref. 10 746 768 / Version 01...
- Page 10 Operation Overlay Mode Specify how data is to be displayed on your CaptiView in the "Overlay mode" options menu. Overlay: The displayed data is superimposed in the eyepiece over the surgical field. All shutters are opened. Image Injection Channel It can be selected in which eye the image shall be injected (Left, Right, Left + Right).
- Page 11 There is a red light in the push-button, signaling that the display is If the CaptiView is connected to an IGS workstation, the switched off and all shutters are open. workstation assumes control of the shutters. If correlated Contact your Leica representative.
-
Page 12: Settings For Captiview
In this chapter you can find detailed description of the XGA assignment. Application 1 – FL800 FL800 Input To prepare the Leica operating microscope to display the signal of a Leica FL800 system for a specified user in the CaptiView. User DIC settings DIC In 1:... -
Page 13: Application 2 - Igs
Settings for CaptiView Application 2 – IGS IGS Input To prepare the Leica operating microscope to display the signal of an IGS system for a specified user in the CaptiView. User DIC settings DIC In 1: No device DIC In 2:... -
Page 14: Application 3 - Common
Settings for CaptiView Application 3 – Common Common Input To prepare the Leica operating microscope to display the signal of e.g. an endoscope for a specified user in the CaptiView. User DIC settings DIC In 1: Common DIC In 2:... -
Page 15: Application 4 - Igs + Fl800
Application 4 – IGS + FL800 IGS + FL800 Input To prepare the Leica operating microscope to display the signal of an IGS system and/or a Leica FL800 for a specified user in the CaptiView. User DIC settings DIC In 1:... -
Page 16: Application 5 - Fl800 + Common
Settings for CaptiView Application 5 – FL800 + Common FL800 + Common Input To prepare the Leica operating microscope to display the signal of a Leica FL800 and/or e.g. an endoscope for a specified user in the CaptiView. User DIC settings... -
Page 17: Application 6A - Igs (1St) + Common (2Nd)
Application 6a – IGS (1st) + Common (2nd) Common + IGS Input To prepare the Leica operating microscope to display the signal of an IGS system (1st priority) and/or e.g. an endoscope (2nd priority) for a specified user in the CaptiView. -
Page 18: Application 6B - Igs (2Nd) + Common (1St)
Application 6b – IGS (2nd) + Common (1st) Common + IGS Input To prepare the Leica operating microscope to display the signal of an IGS system (2nd priority) and/or e.g. an endoscope (1st priority) for a specified user in the CaptiView. -
Page 19: Application 7A - Fl800 (1St) + Igs (2Nd) + Common (3Rd)
Application 7a – FL800 (1st) + IGS (2nd) + Common (3rd) FL800 + Common + IGS Input To prepare the Leica operating microscope to display the signal of a Leica FL800 (1st priority), an IGS system (2nd priority) and/or e.g. an endoscope (3rd priority) for a specified user in the CaptiView. -
Page 20: Application 7B - Fl800 (1St) + Igs (3Rd) + Common (2Nd)
Application 7b – FL800 (1st) + IGS (3rd) + Common (2nd) FL800 + Common + IGS Input To prepare the Leica operating microscope to display the signal of a Leica FL800 (1st priority), an IGS system (3rd priority) and/or e.g. an endoscope (2nd priority) for a specified user in the CaptiView. -
Page 21: Care And Maintenance
• Only original Leica Microsystems spare parts must be used. Protect the CaptiView from improper operation. Disposal Clean the housing of the CaptiView using a moist towel and dry it using a soft, lint-free cloth. • Observe the relevant national regulations on disposing the unit. -
Page 22: What To Do If
Check whether the data source is sending an image. The connector of the XGA video cable or the XGA video Check the cables between OH6 / OHX and CaptiView and the cable is defective or connected incorrectly. external cable source. -
Page 23: Troubleshooting The Shutters
DIC settings set incorrectly. Check the saved positions of the shutters in the "DIC" menu of The position of the shutters saved in the "DIC Settings" the control unit (see page CaptiView) and set them as menu is incorrect. required. -
Page 24: Specifications
ISO 13485 and ISO 14001 relating to quality management, quality assurance and environmental Type 3 transmissive HTPS Panels management. Resolution 1920 × 1080 Pixel Contrast nom. 500:1 (native) Compatibility Color depth 24 bit Systems Leica M530 OH6 Leica M530 OHX CaptiView / Ref. 10 746 768 / Version 01... - Page 25 CaptiView / Ref. 10 746 768 / Version 01...
- Page 26 Specifications CaptiView / Ref. 10 746 768 / Version 01...
- Page 27 Specifications CaptiView / Ref. 10 746 768 / Version 01...
- Page 28 10 746 768/01 • Copyright © by Leica Microsystems (Schweiz) AG, Medical Division, CH-9435 Heerbrugg, 2017• Printed – 02.2017 • Subject to modifications • LEICA and the Leica Logo are registered trademarks of Leica Microsystems...
