- Page 1 U S E R M A N U A L I N A L T O . H O U S E 90cm Gas Cooktop — M O D E L C O D E I C G 9 0 5 W A H I G H E R L E V E L O F C O O K I N G V .
-
Page 2: Welcome
It is important that you read through the following use and care manual thoroughly to familiarise yourself with the installation and operation requirements of your appliance to ensure optimum performance. Again, thank you for choosing an InAlto appliance and we look forward to being of service to you. -
Page 3: Table Of Contents
Contents Welcome 4 Important Instructions 6 Your InAlto Cooktop Before First Use 8 Using Your Cooktop 9 Burners 10 Cleaning and Care 11 Troubleshooting 12 Technical Data 13 Installation Instructions 14 Installation Procedure 16 Gas Connection 20 LPG Conversion 21 Electrical Connection... -
Page 4: Important Instructions
Important Instructions IMPORTANT INFORMATION BEFORE USING YOUR APPLIANCE The following statements you will see in this Before you use the appliance, we recommend booklet have these meanings: that you read through the relevant sections of this manual, which provides the description of WARNING: Indicating information concerning your appliance and its functions. - Page 5 WARNING: Read the following carefully to avoid CAUTION: Read the following carefully to avoid damage or injury. an electric shock or fire. • Do not allow pots to boil dry, as damage to It is important to use your cooktop safely. Check both pan and cooktop may result.
-
Page 6: Your Inalto Cooktop
Your InAlto Cooktop ICG905W Cast Iron Trivets (×3) Semi Rapid Burner (×2) Triple Ring Wok Burner Auxiliary Burner Rapid Burner Stainless Steel Hob Figure 1 Glass Panel beneath the Burner Control Knobs Burner Control Knobs THE BURNER Figure 2A Injector... -
Page 7: Before First Use
Before First Use INSTALLATION CLEANING • An authorised person must install this • Always ensure the appliance is turned off appliance and MUST provide a Certificate before cleaning. of Compliance. This certificate should be • This appliance contains aluminium fittings. Do not use caustic based cleaners. -
Page 8: Using Your Cooktop
Using Your Cooktop CAUTION: Figure 3 • Keep hands clear of burners when lighting. • If burner does not light within 5 seconds, turn STANDARD BURNER knob to ‘OFF’ position, wait to allow gas to disperse and then try lighting again. •... -
Page 9: Burners
Burners CHOICE OF BURNER POTS AND PANS For your convenience there is a choice of burners All common pots and pans; aluminium, stainless to choose from: steel, cast iron, ceramic, etc., may be used on • A small Auxiliary burner for special low heat your new gas cooktop. -
Page 10: Cleaning And Care
Cleaning and Care CAUTION: Ensure the appliance is off and cool TRIVETS AND BURNERS before cleaning. These can all be lifted off and removed for separate cleaning. TRIVETS NOTE: When refitting the burners, ensure that Persistent stains may require rubbing with a nylon scourer or creamed powder cleansers. -
Page 11: Troubleshooting
Troubleshooting If you have a problem with the cooktop, check the table below. You may be able to solve the problem and this will save you from paying for a service call. You will have to pay for a service call even in the warranty period if the problem is one listed below. -
Page 12: Technical Data
Technical Data We reserve the right to alter these specifications. This appliance conforms to AS/NZS 5263. TABLE 2 FEATURES ICG905W Burners Yes, triple Ignition 220–240V Trivet Cast Hob Material Stainless Steel Features Ignition under knob Flame Failure Safety Colours Stainless Steel... -
Page 13: Installation Instructions
• The particular instructions as given below. • A certificate of compliance MUST be given to the customer after the application is successfully installed. Figure 5 – ICG905W 136* 100* Gas Supply Connection 124* * Minimum clearance from cut-out to combustible surface. -
Page 14: Installation Procedure
Installation Procedure • The bench cutout should be made as per • Ensure that there is an earthed power outlet cutout dimensions in Table 2 and Figure 5. within 900mm of the rear left hand side of • Adjacent walls, cupboards and protection the cooktop when installed. - Page 15 Failure to fix the cooktop to the bench could result in loosening of the gas connection through movement of the cooktop and a gas leak may result. Clamps and screws are supplied with each cooktop. Fit the clamps as shown in Figure 6. When benchtops are less than 35mm in thickness, it may be necessary to fit a spacer between the benchtop and each clamp to ensure clamps can be tightened sufficiently.
-
Page 16: Gas Connection
Gas Connection OPERATION ON N.G./S.N.G ELBOW POSITIONING It is possible to reposition the elbow if required This appliance is supplied for use with Natural by loosening the locking nut and elbow by using Gas. However, it can be converted for use with two spanners. - Page 17 CONVERTING THE REGULATOR NOTE: Do not adjust the regulator valve body The Dual Gas Regulator has been factory set to piece in the above procedure, as it will affect the natural gas. To convert the Regulator for use with performance parameters set in the factory. liquefied petroleum gas, follow the steps below.
- Page 18 The ½” tapered thread connects to the outlet of NOTE! the regulator, and is sealed on the thread using approved time as thread sealing tape or approved thread sealing compound. The inlet of the regulator is a ½” parallel thread and •...
- Page 19 CHECKING THE GAS SUPPLY • Check the manometer zero point is correct. • Connect the manometer to the cooktop pressure point. This is located on the regulator. • Turn on the gas supply and electricity and try to ignite the gas. NOTE: It will take additional time to light the gas for the first time as air needs to be purged from the pipes.
-
Page 20: Lpg Conversion
LPG Conversion This appliance is supplied set up for Natural • If the regulator appears to not be performing Gas usage. A conversion kit is included with the satisfactorily then check the following points: product for Universal LPG usage. The conversion •... -
Page 21: Electrical Connection
Diagram 1 is a schematic of the wiring in the WARNING: When the power cord is damaged it appliance. must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. Diagram 1 – ICG905W... -
Page 22: Testing Appliance Operation
Testing Appliance Operation After installation, test the appliance and ensure • If the appliance cannot be adjusted to that it operates correctly before handing it over perform safely inform the customer of the to the customer. The following procedure is problem and affix an appropriate warning recommended: notice to the appliance. - Page 23 Figure 9 Flame size adjusted to maximum Flame size adjusted to minimum Figure 10 Bypass screw...
-
Page 24: Purchase Details
Purchase Details For future reference, please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice. STORE DETAIL S STORE NAME ADDRESS TELEPHONE PURCHASE DATE PRODUCT DETAIL S MODEL NO. -
Page 25: Warranty Information
Simply visit the below website, or ask your retailer 24 months on the microwave magnetron; Waste for help: www.inalto.co.nz/register disposers have a 12 month warranty. The provision of service under this warranty is... - Page 26 Warranty Information AUSTRALIAN WARRANTY TERMS & CONDITIONS This warranty only applies to Appliances COOKING APPLIANCES purchased and used in Australia and is in addition to (and does not exclude, restrict, or This document sets out the terms and conditions modify in any way) any non-excludable statutory of the product warranties for Residentia Group warranties in Australia.
- Page 27 (a) the Appliance is damaged by: failure. The benefits to you given by this warranty accident are in addition to your other rights and remedies (ii) misuse or abuse, including failure to properly under a law in relation to the Appliances or services to which the warranty relates.
