Clarke CHT 454 Instructions For Use

Coil spring compressor set

COIL SPRING

COMPRESSOR SET

MODEL No: CHT 454

Part No: 1801454

GUARANTEE

This CLARKE product is guaranteed against faulty manufacture for a period of

12 months from the date of purchase. Please keep your receipt as proof of

purchase. This guarantee is invalid if the product is found to have been abused

or tampered with in any way, or not used for the purpose for which it was

intended.

Faulty goods should be returned to their place of purchase, no product can

be returned to us without prior permission.

This guarantee does not effect your statutory rights.

Table of Contents

Do you have a question about the CHT 454 and is the answer not in the manual?

Page 1 Part No: 1801454 GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for the purpose for which it was intended.
Page 2 COMPONENTS Part No. Screw Clamp ZHCHT45401 Large Claw 140-200mm ZHCHT45402 Medium Claw 100-140mm ZHCHT45403 Small Claw 67-100mm ZHCHT45404 Hex. Wrtench 6mm ZHCHT45405 Hex. Socket Head Screw 6mm ZHCHT45406 Clamp ZHCHT45407 Parts & Service: Tel: 020 8988 7400 International, Hemnall Street, Epping, Essex CM16 4LG...
Page 3 METHOD OF USE Select the appropriate claws to suit the coil spring, and attach to the screw clamp, securinjg with the hex. socket head screws, using the hex. socket wrench provided. Spare screws are also provided if required. Turn the clamp nut on the end of the clamp, (see Fig.1) to position the claws so that they may be inserted between the coils as shown, ensuring the coils bed...

1801454
