Guldmann GH Service Manual page 19

Electrical installations
Protection against electric shock
g) Bathtub
Area 3
IPx0
Area 1
IPx4
Area 0
IPx7
h) Showerbasin
Area 3
IPx0
Area 1
IPx4
Area 0 - IPx7
i) Shower without basin, with partition wall
Area 3
IPx0
Area 1
IPx4
Area 0 - IPx7
0,05 m
Area 2
IPx4
0,60 m
(2')
Area 1
IPx4
Area 2
IPx4
0,60 m
(2')
Area 1
IPx4
Partition wall
Area 2
IPx4
Ceiling
Outside area
Area 3
IPx0
2,40 m
(8')
Ceiling
Outside area
Area 3
IPx0
2,40 m
(8')
Ceiling
Outside area
Area 3
IPx0
2,40 m
(8')
21
Outside
area
3,00 m
2,25 m
(9 / ')
1
4
(7 / ')
1
2
Outside
area
Lower or
2,25 m
equal to
(7 / ')
1
2
3,00 m
(9 / ')
1
4
Lower or
equal to
3,00 m
/ ')
(9 1
4
2,25 m
(7 / ')
1
2
Outside
area
