Owner's Manual
FREE 24-hour Tech Support: 724-746-5500
blackbox.com
© 2007. All rights reserved. Black Box Corporation.
ServSwitch Brand CATx KVM Extenders
Extend KVM signals over twisted-pair
Extend KVM signals over twisted-pair
cable without sacrificing video clarity!
cable without sacrificing video clarity!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Black Box ACU2009A
Summary of Contents for Black Box ACU2009A
- Page 1 FREE 24-hour Tech Support: 724-746-5500 blackbox.com © 2007. All rights reserved. Black Box Corporation. ServSwitch Brand CATx KVM Extenders Extend KVM signals over twisted-pair Extend KVM signals over twisted-pair cable without sacrificing video clarity! cable without sacrificing video clarity!
- Page 2 FEATURES • Skew compensator on all remote units. • Support high video resolutions at long distances. • Work over CAT5, CAT5e, and CAT6. • Single-access and dual-access kits available. • Serial extenders also send serial port data. • Intelligent keyboard and mouse emulation.
- Page 3 Kit (ACU2001A) performs basic KVM extension and features skew compensation. With the dual-access model (ACU2009A), you can attach an additional monitor, keyboard, and mouse to the local unit, and then operate the PC from either the local or remote user station.
- Page 4 Connectors — ACU2001A: (2) 6-pin mini-DIN F, (1) HD15 M, (1) RJ-45; ACU2009A: (4) 6-pin mini-DIN F, (1) HD15 M, (1) HD15 F, (1) RJ-45; ACUR001A: (2) 6-pin mini-DIN F, (1) HD15 F, (1) RJ-45; ACU2022A: (2) 6-pin mini-DIN F, (1) HD15 M, (1) RJ-45, (2) 3.5-mm audio jacks, (1) DB9 F;...
- Page 5 5-Volt Power Supply for ServSwitch Extender (for ACU2201A-R2, ACU2209A, ACU2222A-R2, and ACU2228A Local Units Only) 9-Volt Power Supply for ServSwitch Extender (for Any Remote Unit) WHAT‘S INCLUDED ACU2001A, ACU2009A, ACU2022A, ACU2028A, ACU2222A-R2, ACU2228A: ACU2201A-R2, ACU2209A: ✦ Local unit ✦ Local unit ✦...
