ServSwitch
Easily extend both HDMI video and USB 2.0
up to 330 feet (100 m).
Customer
Support
Information
ACU2500A
KVM Extender, HDMI and USB 2.0 over CATx
™
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: info@blackbox.com
BLACK BOX
ACU2500A
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Black Box ServSwitch ACU2500A
Summary of Contents for Black Box ServSwitch ACU2500A
-
Page 1: Black Box
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) Customer FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 Support Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Information Web site: www.blackbox.com • E-mail: info@blackbox.com ACU2500A... - Page 2 Trademarks Used in this Manual/FCC and IC RFI Statement Trademarks Used in this Manual Black Box and the Double Diamond logo are registered trademarks, and ServSwitch is a trademark, of BB Technologies, Inc. Mac and OS X are registered trademarks of Apple Computer, Inc.
-
Page 3: Instrucciones De Seguridad
NOM Statement Instrucciones de Seguridad (Normas Oficiales Mexicanas Electrical Safety Statement) 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura. 3. -
Page 4: Table Of Contents
3.5 Checking the Installation ............................13 3.6 Connecting a USB Device ............................13 Troubleshooting ................................. 14 4.1 Problems/Causes/Solutions ............................14 4.2 Contacting Black Box ..............................15 4.3 Shipping and Packaging ............................. 15 A. Technical Glossary ................................16 724-746-5500 | blackbox.com... -
Page 5: Specifications
Chapter 1: Specifications 1. Specifications Color — 36-bit, Deep Color, and x.v Color Emissions — FCC Part 15 Class A, CE, ICES-003 Class A Enclosure Material — Silver anodized aluminum Environmental — RoHS2 (CE) Immunity — CE EN 55024 Latency — Less than 1 ms Power Available to USB Device at Remote Extender —... -
Page 6: Overview
Chapter 2: Overview 2. Overview 2.1 Introduction The instructions in this guide assume a general knowledge of computer installation procedures, familiarity with cabling requirements, and some understanding of USB devices. NOTES provide additional useful and important information. CAUTIONS provide important information about an operational requirement. 2.2 About the ServSwitch KVM Extender, HDMI and USB 2.0 over CATx The Extender incorporates a proprietary USB and HD video technology, which enables users to extend both HDMI video and USB 2.0 up to 330 feet (100 m). -
Page 7: Compatibility And Recommended Setup
Chapter 2: Overview 2.5 Compatibility and Recommended Setup The product is compatible with many graphics cards, operating systems, and monitors, and supports high definition video resolutions of up to 1080p, 1920 x 1200, and 4K. However, there is no guarantee that all devices will be compatible with the product, because there are a number of different factors that may impact the operation of this KVM Extender. -
Page 8: Hardware Description
Chapter 2: Overview HDMI Features The KVM Extender is compatible with the following HDMI features: • Full uncompressed high definition 1080p, 1920 x 1200, and 4K video resolution. • Depth perception of 2D and 3D. • Deep Color and x.v. Color •... - Page 9 OFF when there is no video being transmitted. Link Port (RJ-45) Accepts RJ-45 connector for CAT5e cabling. Config Reserved for use by Black Box. HDMI In Accepts HDMI connector for video input from the host computer. Device Port (USB Type B) Connects the local extender to the host computer.
-
Page 10: Remote Extender
Chapter 2: Overview 2.6.2 Remote Extender The Remote Extender provides HDMI output to a monitor and three USB Type A ports for standard USB devices. Additional devices may be connected by attaching USB hubs. Figure 2-2 shows the front and back panels of the Remote Extender. Table 2-3 describes its components. - Page 11 Accepts RJ-45 connector for CAT5e cabling. HDMI Out Accepts HDMI connector to the remote monitor. Config Reserved for use by Black Box. (3) Device Ports (USB Type A) Accepts USB device(s). Power Port Connects to the 5-V, 3-A power adapter.
-
Page 12: Installation
Chapter 3: Installation 3. Installation Before you can install the product, you need to prepare your site: 1. Determine where the computer is to be located and set up the computer. 2. Determine where you want to locate the remote desktop, including the monitor, keyboard, mouse, and any other USB device(s). -
Page 13: Connecting Power To The Local Extender And Remote Extender
Chapter 3: Installation With Premise Cabling 1. Plug one end of a CAT5e patch cord (not included) into the Link port (RJ-45) on the Local Extender. 2. Plug the other end of the patch cord into the CAT5e information outlet near the host computer. 3. -
Page 14: Troubleshooting
7. Reconnect the Local Extender unit to the computer. 5. The unit is malfunctioning. 8. If the USB LED continues to stay off, contact Black Box Technical Support at 724-746-5500 or info@blackbox.com. 1. Disconnect the KVM extender product from the computer. -
Page 15: Contacting Black Box
If you determine that your ServSwitch KVM Extender is malfunctioning, do not attempt to alter or repair the unit. It contains no user-serviceable parts. Contact Black Box Technical Support at 724-746-5500 or info@blackbox.com. Before you do, make a record of the history of the problem. We will be able to provide more efficient and accurate assistance if you have a complete description, including: •... -
Page 16: Technical Glossary
Appendix A: Technical Glossary Appendix A. Technical Glossary Category 5 (CAT5) Network Cabling — Category 5 cable is commonly also referred to as CAT5. This cabling is available in either solid or stranded twisted pair copper wire variants and as UTP (Unshielded Twisted Pair) or STP (Shielded Twisted Pair). UTP cables are not surrounded by any shielding, making them more susceptible to electromagnetic interference (EMI). - Page 17 NOTES ACU2500A Page 17...
- Page 18 NOTES 724-746-5500 | blackbox.com ACU2500A Page 18...
- Page 19 NOTES ACU2500A Page 19...
- Page 20 About Black Box Black Box provides an extensive range of networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 60 seconds or less.
