Section 4 - Pocket Headbox Dimensions - Draper FlexShade Instructions Installation & Operation

Dual Roller Coupled Motorized FlexShade

Section 4 - Pocket Headbox Dimensions

"
19mm
Extra Large Dual Roller
with Pocket Headbox
HEADBOX CLIP
(without optional
tile support)
SHADE WIDTH
Pocket Headbox
CLOTH WIDTH
®
(Extra Large Hardware)
8 "
(221mm)
3"
(76mm)
CLOSURE PANEL
page 5 of 12
CONTINUOUS
BLOCKING
BY OTHERS
7 "
(197mm)
CONTINUOUS BLOCKING
" BY OTHERS
(21mm)
CEILING
HEADBOX CLIP
BY OTHERS
(with optional
tile support)
7 "
(197mm)
"
(21mm)
