SECTION 8

8.1 STANDARD CIRCUIT BOARDS

Power Board
Control Board
Terminal Board
8.2 OPTIONAL CIRCUIT CARDS
DC Tach Option Card
Pneumatic Enclosure Assembly
Isolated Output Card
Non-Standard Servo Valve Driver Card
V-Out Board
Pulse Tach /Encoder Option Card 723-0078

8.3 OUTPUT MODULES

SCR bridge
Servo valve

8.4 FUSES

(Slo Blo type)
Power in: 0.25A/250V
5A/250V
0.125A/250V
Power out: 5A/250V

8.5 CABLES

14 Conductor, Ribbon
24 Conductor, Ribbon
34 Conductor, Ribbon
6 Conductor
6 Conductor

8.6 RELAYS

TLS Tension Limit Relay
REPLACEMENT PARTS LIST
723-1324
723-2020
723-2022
723-0101
723-2037 (Version P)
723-1439 (Version D)
723-1409 (Version C)
723-1346 (Version V)
103-0013 (High voltage output module for version V)
119-0003 (For version P only)
108-0046 (All versions of controller, 115 Vac)
108-0003 (For version V only, on V-Out Board)
108-0045 (230 Vac)
108-0003 (For version V only, on V-Out Board)
131-0000 (Output Module board to Control Board)
723-1362 (Terminal board to Control Board)
723-1313 (Control Board to Power Board)
721-1910 (Internal cable: Control Board to RPE port)
721-1776/77 (WebHandler™ to Pneumatic module) Ver.P
105-0028
