Modu-licious #3
DESI GNED IN 19 99
AS SEM BLY N OT ES | R E V 00
Y O U W A N T C H O I C E S , W E G O T C H O I C E S .
Drawers and doors are your canvas with the award-winning
Modu-licious series.
N E E D A H A N D ?
Contact us at service@bludot.com or
844.425.8368 for assistance.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Modu-licious 3 and is the answer not in the manual?

Questions and answers

Related Manuals for BluDot Modu-licious 3

Summary of Contents for BluDot Modu-licious 3

  • Page 1 Y O U W A N T C H O I C E S , W E G O T C H O I C E S . N E E D A H A N D ? Contact us at service@bludot.com or Drawers and doors are your canvas with the award-winning 844.425.8368 for assistance.

  • Page 2: Parts & Hardware

    Parts & Hardware Pt. 5005 Pt. 5002 Pt. 5001 Pt. 8016 8015 Modu-licious door kit Rubber Stop 15mm 8041 8014 Pt. 4005 Pt. 8018 Pt. 8015 Pt. 1206 Modu-licious door kit Anti-tip Bracket 8042 Steel Rod 374mm t7mm Anti-tip Strap Pt.
  • Page 3 Parts & Hardware Pt. 8045 Door Stretcher Partition Panel Foot Side Panel Back Panel Center Panel Bottom Panel Top Panel *panel has grooves on both sides *panel has drilled holes on both sides A S S E M B L Y N O T E S S E R V I C E @ B L U D O T .

  • Page 4: How To Use The Cam Lock System

    How to use the cam lock system How to use the cam lock system Note direction of cam arrow. Turn cam clockwise 1/2 turn or until tight. Note direction of cam arrow. 3 | 8 4 4 . 4 2 5 . 8 3 6 8 M O D U - L I C I O U S # 3...
  • Page 5 Step 01 A S S E M B L E B A S E . Using the stretcher and feet assemble the base as shown. Refer to page 3 on how to use the cam lock system. Finished edge PT. 5 00 1 x 2 PT.
  • Page 6 Step 02 AT TA C H B O T T O M PA N E L . Attach the bottom panel to the base using the provided hardware as shown. Refer to page 3 on how to use the cam lock system. Bottom panel PT.
  • Page 7 Step 03 B E G I N A S S E M B L I N G C A S E . Attach side panels to center panel as shown using the provided hardware. Be sure to align grooves on center and side panels. Refer to page 3 on how to use the cam lock system.
  • Page 8 Step 04 I N S E R T B A C K PA N E L S . Add rubber grommets to each back panel as shown. Insert back panels into grooves in case. PT. 8 01 8 x 4 7 | 8 4 4 .
  • Page 9 Step 05 F I N I S H A S S E M B L I N G C A S E . Finish assembling the case by attaching the top and bottom panels as shown using the provided hardware. Refer to page 3 on how to use the cam lock system.
  • Page 10 Step 06 I N S E R T I N G T H E PA R T I T I O N PA N E L S . Attach the metal brackets and magnet catches as shown. Align partition panel grooves with brackets and slide into place.
  • Page 11 Step 07 AT TA C H D O O R B U M P E R S . Attach the door bumpers as shown using the provided hardware. Modu-licious door kit Rubber Stop 15mm 8015 Modu-licious door kit Rubber Stop 15mm Modu-licious door kit Rubber Stop...
  • Page 12 Step 08 I N S TA L L D O O R S . To install the doors, start by sliding the metal rod through the brackets on the back of each door. Next install doors as shown below. 8014 Modu-licious door kit Steel Rod 374mm t7mm P T.
  • Page 13 Step 09 AT TA C H A N T I -T I P B R A C K E T T O T H E W A L L . Install anti-tip bracket to wall stud 1-inch below case top panel height. 1”...
  • Page 14 Step 10 I N S TA L L A N T I -T I P B R A C K E T T O C A S E . Bracket must be installed to top panel of case. In order to prevent damage, it is recommended that 3/32”...
  • Page 15 Step 11 S E C U R E T H E C A S E . Install and tighten the strap prior to using the product. 8042 Anti-tip Strap PT. 80 4 2 x 1 A S S E M B L Y N O T E S S E R V I C E @ B L U D O T .

  • Page 16: Additional Information

    Additional Information C LEAN Clean with a slightly damp, soft cloth. To remove dirt and fingerprints, use a quality cleaner formulate for wood furniture. Wipe completely dry with a soft cloth in the direction of the wood grain. B L U D O T D E S I G N & M A N U F A C T U R I N G , I N C . D E S I G N E D I N M I N N E A P O L I S , M N...
