- Page 1 D E S I G N E D I N 2 0 1 6 A S S E M B LY N O T E S | R E V 0 0 N E E D A H A N D ? Contact us at service@bludot.com or 844.425.8368 for assistance.
-
Page 2: Parts & Hardware
5023 Parts & Hardware M8X1.25 X 77mm RAIL BOLT Pt. 1089 Pt. 5023 Pt. 5019 Pt. 5018 Pt. 9016 Pt. 9022 Front Upright Rear Upright Headboard *Twin bed ships with x8 PT.1089. 1 | 8 4 4 . 4 2 5 . 8 3 6 8 P O S T U P B E D... - Page 3 Parts & Hardware Upper Rear Rail Lower Rear Rail Slats Side Rail Center Rail Footboard *Twin bed ships with x1 set of slats and no center rail. A S S E M B LY N O T E S S E R V I C E @ B L U D O T. C O M | 2...
- Page 4 Step 01 B E G I N A S S E M B L I N G F R A M E . Attach PT. 5023 to front upright as shown. Repeat for remaining front upright. 5023 M8X1.25 X 77mm RAIL BOLT PT.
- Page 5 Step 03 S E C U R E F O O T B O A R D. Engage drop-in connectors by pulling down on footboard while pushing up on front uprights. Secure the connection by using the provided hardware as shown. PT.
- Page 6 Step 05 B E G I N I N S TA L L I N G U P P E R R E A R R A I L . PT. 50 1 9 1. Place rear uprights and upper rear rail on floor as shown. 2.
- Page 7 Step 07 AT TA C H S I D E R A I L S . Attach the side rails as shown using pre-attached drop-in connectors. Once attached secure side rails using the provided hardware. NOTE: Pre-attached metal brackets should be at headboard side of frame. metal bracket PT.
- Page 8 Step 08 AT TA C H F O O T B O A R D A S S E M B LY. With a second person, lift the side rails and attach the footboard assembly using the pre-attached drop in connectors. Once attached, secure the side rails using the provided hardware as shown.
- Page 9 Step 09 AT TA C H L O W E R R E A R R A I L . Attach the lower rear rail using the pre-attached metal connectors. Tighten pre-attached bolts after rail is in place. bolts Step 10 AT TA C H H E A D B O A R D.
- Page 10 Step 11 I N S TA L L C E N T E R R A I L . Install center rail as shown using the pre-attached metal connectors. NOTE: Twin bed does not ship with a center rail. Step 12 I N S TA L L S L AT S .
-
Page 11: Additional Information
Step 13 S E C U R E S L AT S . Secure slats as shown using the provided hardware. NOTE: Twin bed ships with one set of slats and x2 fewer PT. 1089. PT. 1 08 9 x 4 * PT. - Page 12 B L U D O T D E S I G N & M A N U F A C T U R I N G , I N C . D E S I G N E D I N M I N N E A P O L I S , M N...
