- Page 1 K E E P T H E S T U F F Y O U L I K E A N D S T O R E I T W E L L . N E E D A H A N D ? Contact us at service@bludot.com or Drawers and doors are your canvas with the award-winning Modu-licious series.
-
Page 2: Parts & Hardware
Parts & Hardware Pt. 5001 Pt. 1023 Pt. 4005 Pt. 8018 Pt. 5002 Pt. 5005 foot Drawer Slide Stretcher Top Panel Bottom Panel Back Panel Side Panel Drawer 1 | 8 4 4 . 4 2 5 . 8 3 6 8 M O D U - L I C I O U S # 1... -
Page 3: How To Use The Cam Lock System
How to use the cam lock system Note direction of cam arrow. Turn cam clockwise 1/2 turn or until tight. Note direction of cam arrow. A S S E M B L Y N O T E S S E R V I C E @ B L U D O T . C O M | 2... - Page 4 Step 01 A S S E M B L E B A S E . Using the stretcher and feet assemble the base as shown. Refer to page 2 on how to use the cam lock system. PT. 5001 x 2 PT.
- Page 5 Step 02 AT TA C H B O T T O M PA N E L . Attach the bottom panel to the base using the provided hardware as shown. Refer to page 2 on how to use the cam lock system. Bottom Panel PT.
- Page 6 Step 03 AT TA C H D R A W E R S L I D E S . Attach drawer slides to side panel as shown using provided hardware. Repeat for right panel Left Side Panel PT. 10 23 X 8 5 | 8 4 4 .
- Page 7 Step 04 B E G I N A S S E M B L I N G C A S E . Attach side panels to base as shown using the provided hardware. Be sure to align grooves. Refer to page 2 on how to use the cam lock system.
- Page 8 Step 05 I N S E R T B A C K PA N E L S . Add rubber grommets to panel as shown. Insert back panels into grooves in case. PT. 80 18 X 2 7 | 8 4 4 . 4 2 5 . 8 3 6 8 M O D U - L I C I O U S # 1...
- Page 9 Step 06 AT TA C H T H E T O P. Attach top panel as shown using the provided hardware. Refer to page 2 on how to use cam lock system. PT. 50 0 1 x 6 PT. 5 00 2 x 6 PT.
- Page 10 Step 07 I N S TA L L D R A W E R S . To install the drawers extend drawer slides out from case, align with drawer slides as shown, and slide drawer in. Be sure to push until drawer is completely closed and engaged.
-
Page 11: Additional Information
Additional Information TO R E M OVE DR AWE RS Pull lever up on the right side and push down on the left side of the drawer slide. With levers engaged pull drawer out. TO AD JU ST D RAWE R FR ONTS Loosen the acorn nuts, adjust drawer front, re-tighten acorn nuts. - Page 12 B L U D O T D E S I G N & M A N U F A C T U R I N G , I N C . D E S I G N E D I N M I N N E A P O L I S , M N...
