- Page 1 Owner Manual Featuring Connect+ GAMMA-S GAMMA-X ELECTRIC BICYCLES Hand Built in Europe batribike.com...
- Page 2 Keep your receipt for a minimum of 5 years as it is your proof of purchase and entitlement to warranty. For your safety and to ensure a long and trouble free life of your Batribike bicycle, check the operation of brakes, lights, bell and gears, and check tyre pressures are correct.
-
Page 3: Table Of Contents
Thank you for purchasing a BATRIBIKE Electric Bicycle With care and correct usage your bicycle will give many years of service. Important PLEASE CHARGE THE BATTERY BEFORE FIRST USING THE BICYCLE Even though the battery indicator will show charge this cannot be relied upon until the battery has had the initial full charge. -
Page 4: Parts Identification
PARTS IDENTIFICATION We continually strive to ensure that we provide you with the best possible products, therefore SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE Rear Brake Lever Seat Adjust (Position) - Front/Back Handlebar Adjust (Bar Rotation) Seat Adjust (Height) - Clamp Bell Front Brake Lever Front LED Light... - Page 5 OTHER SIDE HANDLEBAR DISPLAY OPTIONS STANDARD FITMENT (Connect+ LED) SHOWN LEFT CONNECT+ SYSTEM CAN ALSO BE CONTROLLED BY SMART PHONE APP. (NOT SHOWN)
-
Page 6: Battery Care & Charging
BATTERY CARE & CHARGING Your Batribike Electric Bicycle uses a Lithium battery for it's power and the following points will directly affect battery life and performance. First time use Your battery will be supplied in a state of sleep from the factory. The first time you use the battery it requires activation by being fully charged. - Page 7 Using the Charger Two types of battery charger are used by BATRIBIKE. (Only one will be supplied). Both have a charge light which will display RED when charging and change to GREEN when the battery is charged. The alternative type charger also has a second light which shows RED when mains power is applied.
-
Page 8: Using The Power Assistance
Usage Your BATRIBIKE electric bicycle has the CONNECT+ system fitted as standard to the bike. The bicycle can be operated with just the handlebar mounted control / display or, with enhanced, additional features via your smartphone. Connect+ See separate manual for operation LED display fitted as standard. - Page 9 Pedal Assistance - Fitted LED display There are 5 levels of pedal assistance available from the motor. Using the UP and DOWN buttons you can select from Level 1 (Lowest), to Level 5 (Highest). The motor will then be activated upon pedalling. PEDAL ASSISTANCE FROM THE MOTOR LEVEL / RANGE EXAMPLE OF USAGE...
-
Page 10: Standard Bicycle Functions
STANDARD BICYCLE FUNCTIONS Gears Your BATRIBIKE is provided with 8 speed derailleur gears with twin lever gear changers. To change gear you use the right handlebar levers for the rear 8 speed. Gear number 1 is low for hills and rough terrain and gear 8 is high for normal road use. - Page 11 Braking To stop, cease pedalling and pull the brake levers. Also ensure that the throttle is not operated. Remember that the GAMMA is equipped with powerful hydraulic brakes and will stop quickly. Braking will be less effective in wet conditions and your riding style should be adjusted accordingly.
-
Page 12: Adjusting To Suit The Rider
The height of the saddle can be adjusted to suit the rider. If you do not feel confident with making these adjustments then your BATRIBIKE Dealer will be able to set up the bike initially. The saddle height is adjusted... - Page 13 The handlebars can be adjusted in a similar manner by loosening the Allen Bolt in the recess on the handlebars and moving up or down, then retightening. Take care not to exceed the limit marked on the stem. The handlebar rake angle can be adjusted to suit the rider. Loosen the Allen Bolt located below the riser.
-
Page 14: Removing The Battery
Removing the Battery To remove the battery, turn off at the handlebar display, unlock the battery using the key provided. Push the battery locking tab downwards away from the battery and using the finger insert pull the lower part of the battery downwards and angle the battery out of the frame. - Page 15 Your Local Authority should have the necessary facilities in place. If you prefer you may take your original battery to BATRIBIKE for recycling. Never dispose of batteries in a fire or subject to puncture or crushing.
-
Page 16: Maintenance Schedule
Beyond this manual, it is good to consult your BATRIBIKE dealer for advice if you are at all unsure about any of the procedures described. Normal maintenance is not covered under the warranty and this service may be chargeable. - Page 17 After 3,000 miles (5,000 km) (or YEARLY if sooner) ● General inspection We recommend you arrange to have a thorough inspection of your bicycle by a BATRIBIKE dealer. Tyre Pressures Recommended Tightening Torques Item Torque Item Torque The tyres should be...
-
Page 18: Warranty
Cost incurred by loss of the bicycle’s usage. Brake blocks/pads, tyres, lights and cables etc. are considered as consumables and replacements are available from BATRIBIKE or may be obtained from your local cycle shop. In the event of a Warranty claim ●... - Page 19 5. In the unlikely event of a battery failure, the battery must be returned to Batribike, via your Batribike dealer for testing. If upon testing it is found that the above conditions have not been met then the warranty will not apply and the cost of replacement and carriage will be payable by the Customer.
-
Page 20: Specifications
GAMMA-S - Specifications (SUBJECT TO CHANGE WITHOUT NOTICE) MOTOR GEARS 250W centre mounted 8 Speed microSHIFT Gears and shifter High Torque (100 Nm) Promovec Motor with 3 year Warranty BRAKES WEIGHT of BIKE Shimano hydraulic disc brakes front 22.0 kg (48.5 lbs) without battery and rear 24.1 kg (53.1 lbs) with Eco battery WEIGHT of BATTERY... - Page 21 GAMMA-X - Specifications (SUBJECT TO CHANGE WITHOUT NOTICE) MOTOR GEARS 250W centre mounted 8 Speed microSHIFT Gears and shifter High Torque (100 Nm) Promovec Motor with 3 year Warranty BRAKES WEIGHT of BIKE Shimano hydraulic disc brakes front 22.0 kg (48.5 lbs) without battery and rear 24.1 kg (53.1 lbs) with Eco battery WEIGHT of BATTERY...
-
Page 23: Safety Notices
See pages 6 and 7 for full battery care and charging. See page 15 for battery disposal. Product Description Your Batribike has been produced according to the guidelines in European standard EPAC EN 15194:2017 and the classification according to EN 17406, Trekking Bike. - Page 24 Batribike Limited Unit 4, Ingleby Grange Ingleby Lincoln BATRIBIKE are LN1 2PQ Members of the Phone: 01427 787774 Bicycle Association of Great Britain E-mail: support@batribike.com ----- USER MANUAL GAMMA - ISSUE 4 - ©2021 Batribike Limited -----...
