Summary of Contents for Growatt MID 10KTL3-X

  • Page 1 Installation & Operation Manual Growatt New Energy Download Manual Shenzhen Growatt New Energy Technology CO.,LTD No.28 Guangming Road, Shiyan Street, Bao’an District, No.28 Guangming Road, Shiyan Street, Bao’an District, Shenzhen, P.R.China Shenzhen, P.R.China +86 755 2747 1942 +86 755 2747 1942 service@ginverter.com...
  • Page 2 Index Notes on this Manual 1.1 Validity 1.2 Target Group 1.3 Additional information 2 Introduction 2.1 Foreword 2.2 Applicable personnel 2.3 Product overview and features 2.4 Safety instructions 3 Product Description 3.1 Appearance overview 3.2 Dimensions 3.3 Storage environment Unpacking and Inspection 5 Installation 5 1 Basic installation requirements Mounting wall mount...
  • Page 3 6 Inverter Wiring 11 Start the Inverter 6.1 Safety 11.1 Start the inverter 6.2 AC side wiring 11.2 Shut down the inverter 6.3 DC side wiring 6.4 Connecting signal line 7 Debugging 12 Fan Maintenance 8 Operating Mode 13 Troubleshooting 8.1 Normal mode 13 1 Error message 8.2 Failure mode...
  • Page 4: Notes On This Manual

    As shown in Figure above, a complete PV grid-connected system includes PV modules, product. Any changes to this manual by Growatt New Energy will not be notified to the PV inverters, public grids, and other components. In photovoltaic module systems, user.
  • Page 5 2.4.1 Sign convention 2.3.2 Product features The characteristics of the inverter are as follows: Sign Explanation Dual independent maximum power point tracking Ÿ Built-in DC switch Ÿ Compatible with RS485/Wifi / GPRS / 4G communication Ÿ 200V-1000V input voltage range Ÿ...
  • Page 6: Product Description

    3 Product description Description of the identification on the inverter: 3.1 Appearance Overview Identification Description Explanation Touch button: we can switch OLED display and Knock mark set parameters by touch. Indicates the current operating state of the inverter. Inverter status red: fault identification green: normal operation...
  • Page 7: Unpacking And Inspection

    4 Unpacking and Inspection Installation 5 5.1 Basic installation requirements Before opening the inverter package, please check the outer packaging for damage. The wall on which the inverter is mounted must be sturdy and can withstand the Ø After unpacking, check the inverter for damage or missing accessories. In the event of weight of the inverter for a long time (refer to the specifications in Chapter 12 for the damage or missing accessories, please contact your dealer.
  • Page 8 Ø Make sure that the inverter is installed in a suitable place and is not allowed to be installed in a closed box; fig5.2 Mounting dimensions for an inverter fig5.4 Closed box Ø In order to reduce the inverter load and extend the life of the inverter due to direct sunlight, we recommend installing a awning.
  • Page 9: Inverter Wiring

    Inverter Wiring 6 Secure the wall mount as shown, do not let the screws flush with the wall, instead expose 6.1 Safety 2 to 4 mm. A high voltage in the conductive part of the inverter may cause an electric shock. Therefore, when performing any installation work on the inverter, make sure that the AC and DC sides of the inverter Danger are powered off.
  • Page 10 Switch specification MID 6KTL3-XL 25A/127V MID 8KTL3-XL 32A/127V Recommended line length: MID 10KTL3-XL 40A/127V MID 11KTL3-XL 40A/127V MID 12KTL3-XL 50A/127V MID 10KTL3-X 32A/230V Maximum wire length Wire MID 12KTL3-X 40A/230V MID 15KTL3-X 40A/230V cross MID 6-8K MID 10-11K MID 12K...
  • Page 11 6.3 DC side wiring The MID series inverter has two independent inputs, as shown below: Ø When the sun shines on the panel, voltage will be generated. The high voltage after the connection may cause life-threatening. Therefore, before connecting the DC input line, the panel should be shielded with opaque material before operation, and the inverter is ensured.
  • Page 12 6.4 Connecting signal line The MID series inverter has an 8Pins signal connector, and the client signal line port is as 3.Dock the client to the inverter plug until both are tightly locked to the inverter. follows: The inverter side fig6.10 Quick installation instructions fig6.7 Quick installation instructions Disassemble the signal connector...
  • Page 13: Operating Mode

    7 Debugging OLED Display and Touch Buttons 9 9.1 Boot display 1) Close the DC switch on the inverter. As long as the input DC voltage is greater than The OLED display can display the operating status of the inverter and various parameter 250V, the inverter display will display the following message: There is no AC connection information.
  • Page 14 The main settings are as follows: 9.1.3 Parameter setting (advanced setting) General settings Advanced Password Password Password Password settings Setting item Language settings Address setting Date setting Time setting Password Password Password Wrong Password Advanced settings(requires password) Country/Region Country/Region Country/Region Country/Region Country/Region Country/Region...
  • Page 15: Communication And Monitoring

    10 Communication and Monitoring Start and Shut Down the Inverter 11 10.1 RS485 11.1 Start the inverter This series of inverters provides two RS485 ports. You can monitor one or more inverters 1. Close the inverter AC circuit breaker. via RS485. Another RS485 port is used to connect to a smart meter (single machine anti- 2.
  • Page 16: Troubleshooting

    3. Disconnect the fan connector, remove the fan fixing plate screw with a screwdriver, In some cases, you may be advised to contact Growatt, please provide the following and finally remove the fan. information.
  • Page 17 13.2 Syetem error Warning Code Fault Discription Suggestion 13.2.1 Warning code 1. Please confirm grid is lost or not. Warning 300 No Utility 2. If error message still exists,contact Warning Code Fault Discription Suggestion manufacturer. 1. After shutdown,Check the panel is 1.
  • Page 18 Warning Code Fault Discription Suggestion Error Code Fault Discription Suggestion 1. Restart inverter. 1. Check grid voltage. Warning 404 EEPROM abnormal. 2. If error message still exists,contact 2. If the error message still exists despite the manufacturer. Error 300 AC V Outrange grid voltage being within the tolerable range, contactmanufacturer.
  • Page 19 Error Code Fault Discription Suggestion Error Code Fault Discription Suggestion 1: After shutdown,Check the output current 1. Restart inverter. Output current is not balanced. Over current protected Error 403 Error 416 2. If error message still exists,contact unbalance 2: If the error message still exists, contact by software manufacturer.
  • Page 20: Specification

    14 Specification 14.1 Parameter Model Specifications 6KTL3-XL 8KTL3-XL 10KTL3-XL 11KTL3-XL 12KTL3-XL Model Specifications 6KTL3-XL 8KTL3-XL 10KTL3-XL 11KTL3-XL 12KTL3-XL Protection devices DC reverse-polarity Input data(DC) protection Max. recommended PV DC switch 7800W 10400W 13000W 13000W 15600W power(for module STC) DC Surge protection typeII Max.
  • Page 21 Model Model MID 10KTL3-X MID 12KTL3-X MID 15KTL3-X MID 17KTL3-X MID 10KTL3-X MID 12KTL3-X MID 15KTL3-X MID 17KTL3-X Specifications Specifications Protection devices Input data(DC) DC reverse-polarity Max. recommended PV protection 13000W 15600W 19500W 22100W power(for module STC) DC switch Max. DC voltage...
  • Page 22 Model Model MID 20KTL3-X MID 22KTL3-X MID 25KTL3-X MID 20KTL3-X MID 22KTL3-X MID 25KTL3-X Specifications Specifications Protection devices Input data(DC) DC reverse-polarity protection Max. recommended PV power(for 26000W 28600W 325000W module STC) DC switch Max. DC voltage 1100V DC Surge protection typeII Insulation resistance monitoring Start voltage...
  • Page 23 Shine LAN-X USB interface LAN monitoring module Repair of the inverter can be on-site repair or transport the inverter to the Growatt Service Center for repair, or replace the new machine with the equivalent of the machine model and age.
