- Page 1 DOMEKT C8 automation INSTALLATION MANUAL...
-
Page 2: Table Of Contents
CONTENT 1. INTRODUCTION ...........................................3 1.1. Safety requirements ......................................3 1.2. Design of the units .......................................3 1.2.1. Classification of units by duct connection side ..........................5 1.2.2. Switching inspection side of DOMEKT R 200 V ..........................6 1.3. Components ...........................................7 1.3.1. Vertical units .......................................7 1.3.2. -
Page 3: Introduction
This way the outdoor air passes around the recuperator and enters the premises directly. Air bypass Air ter Air ter Counter- ow heat Heater or exchanger cooler UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01 Air ter... - Page 4 Chapter “Electrical Installation”). For information on how to set a frost protection mode , see “Domekt User Manual”. Depends on the unit components. Only in CF units. UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01...
-
Page 5: Classification Of Units By Duct Connection Side
Right inspection side Left inspection side Air duct to the premises Air duct to the premises Fig. 2. Classification of units by inspection side Depends on your order. UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... -
Page 6: Switching Inspection Side Of Domekt R 200 V
Section 3.4). In other cases, when the unit is mounted on a wall, you can remove these mounting plates and swap the front and back panels for the unit to look nicer. UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... -
Page 7: Components
– rotary heat exchanger D – exhaust air – outdoor air filter – C8 controller main board E – additional extraction (air bypass without recuperation) F – kitchen hood connection UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... -
Page 8: Flat Units
– rotary heat exchanger D – exhaust air – outdoor air filter – C8 controller main board E – additional extraction (air bypass without recuperation) F – kitchen hood connection UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... -
Page 9: Unit Transportation
After delivery of the air handling unit, carefully inspect its packaging for damage. If mechanical or other damage is visible (e.g., wet cardboard packaging), notify the carrier immediately. If the damage is significant, do not accept the unit. Inform the selling company or the representative of UAB KOMFOVENT within three business days about any damage detected during delivery. -
Page 10: Mechanical Installation
Depends on your order. Only for units to be mounted on the wall or ceiling. 2, 3 UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... - Page 11 • Only these units can be mounted on the ceiling or wall and only in such positions as specified in Fig. 5. UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01...
-
Page 12: Humidity In The Installation Room
– Domekt R 200 V Left – Right – – Domekt CF 200 V Left – – Right – – Domekt CF 300 V Left – – UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... -
Page 13: Flat Units
Domekt CF 200 F – Adhesive anti-vibration gasket Unit A, mm B, mm Domekt R 300 F 1030 – Rubber vibration absorbers Domekt CF 250 F 1190 UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... -
Page 14: Dimensions Of Domekt R 200V With A Kitchen Hood
Dimensions with a standard kitchen hood 140 x 4 = 560 140 x 4 = 560 Dimensions with 392-12 kitchen hood 140 x 4 = 560 140 x 4 = 560 UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... -
Page 15: Domekt R 200 V And Kitchen Hood Installation
Front panel of R 200 V unit is equipped with mounting plates for furniture panel mounting. Mounting plates are screwed to a furniture panel and then the panel can be hung on the front of the unit. UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... -
Page 16: Duct System Installation
It is recommended to insulate the ducts in unheated rooms (attic, basement) to avoid heat loss. It is also recommended to insulate the supply air ducts if the unit is used for room cooling. UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... - Page 17 Spring return actuator with end position contacts (e.g. Belimo LF-230S) Air closing damper Additional extraction duct Air handling unit Fig. 7. Example of mounting of an additional air extraction duct UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01...
- Page 18 Domekt R 200 V Domekt R 300 F Domekt CF 250 F Domekt CF 300 V Duct A Duct B Duct C Duct D Duct E – UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01...
-
Page 19: Connection Of External Heating/Cooling Units
Ordered separately. It is recommended to use PPU made by Komfovent. UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... -
Page 20: Connection Of Condensate Drain
The condensate collection point should be easy to clean and disinfect. Fig. 9b. Condensate drain connection to sewer system UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... -
Page 21: Electrical Installation
Controller board type and QR code for the Komfovent Control app Connections for internal components Terminals for connection of external elements Power supply connector Fig. 10. C8 controller main board UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... - Page 22 Optional fire damper controller must be configured and connected. Refer to Fire damper controller manual for more information. Only in CF 150 F, CF 200 V, CF 300 V units. UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01...
- Page 23 • FG1 (19–21) – terminals used to connect air damper actuators. 230 V power supply actuators with or without a spring return can be connected to them. UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01...
-
Page 24: Control Panel Installation
Yellow Yellow +24V +24V 4 x 0,22 mm 2 4 x 0,22 mm 2 < 150 m < 150 m Fig. 14. Control panel cable wiring diagram UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... -
Page 25: Connecting The Unit To An Internal Computer Network Or The Internet
Internet. The unit is controlled by a computer using a web browser, or a smartphone with a Komfovent Home or Komfovent Control app. The air handling unit is connected to the computer network with a CAT5 type cable (RJ45 connector;... - Page 26 • The easiest way to manage your unit over the internet is to use a smartphone with the Komfovent Control app. Launch the app on your phone (the phone must have Internet access). When you connect for the first time, the app will ask you to scan the QR code at the front of the controller board (see Fig.
-
Page 27: Starting And Checking The Unit
Vėdinimo intensyvumas 100% Ventilation Pageidaujama Pageidaujama Pageidaujama Pageidaujama 100% intensity temperatūra temperatūra temperatūra temperatūra 20°C 20°C 20°C 20°C 20°C 20°C 20°C 20°C temperature Depends on your order. UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... -
Page 28: Control Panel C6.1
To turn off the air handling unit and return to the home screen: 16:30 Menu Menu Menu Overview Overview Overview TURN OFF? Scheduling Planavimas Scheduling INTENSIVE Settings Settings Settings TURN OFF TURN TURN ON AUTO UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... -
Page 29: Control Panel C6.2
Should you forget a changed password, it can be reset to the initial “user”. To do this, you must restore the factory settings for the air handling unit using control panel. UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01... - Page 30 OPERATION MODES АUТО AWAY NORMAL INTENSIVE BOOST АUТО AWAY NORMAL INTENSIVE BOOST KITCHEN FIREPLACE OVERRIDE HOLIDAYS MODIFY > MODIFY > KITCHEN FIREPLACE OVERRIDE HOLIDAYS MODIFY > MODIFY > UAB KOMFOVENT we reserve the right to make changes without prior notice DOMEKT_C8_21-01...
-
Page 31: Quick Check
