  • Page 1 DOMEKT INSTALLATION AND SERVICE MANUAL...

  • Page 3: Table Of Contents

    For more information about where you can drop off your waste equipment for recycling, please contact your local city office, waste authority, approved WEEE scheme or your household waste disposal service. UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...

  • Page 4: Safety Requirements

    The entire unit is wrapped up in protective film. For transit or storage, units are mounted on timber pal- lets. The unit is fastened to the pallet with polypropylene packing tape over protective corners. Vertical and horizontal units ready for transit and storage 1 Picture UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...

  • Page 5: Brief Description Of The Unit

    KOMFOVENT should be notified within three days of receipt, with a written confirmation sent within seven days. KOMFOVENT can accept no responsibility for damage by unloading from carrier or for subsequent damage on site.
  • Page 6 For this reason anti-frost protection function is foreseen in the con- troller of the Komfovent air handling units. Depending on the type of the air handling unit, different methods of anti-frost protection are available: cold air by-passing, supply air fan speed reducing and/or integrated preheater.
  • Page 7 Air temperature of the premises where the unit is mounted, °C 3 picture. Condensation on unit surface diagram UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...
  • Page 8 (20%). In that way, good indoor climate will be maintained and condensation inside of the unit will decrease, avoiding humidity damage to electronic components. UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...
  • Page 9 Air Handling Units Schemes DOMEKT R 190V / 200V DOMEKT R 250 F C6 DOMEKT R 300V DOMEKT R 500V** / DOMEKT R 700V** DOMEKT R 600H DOMEKT R 700H UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...
  • Page 10 DOMEKT R 400F DOMEKT R 700F DOMEKT CF 250 F DOMEKT CF 400 V DOMEKT CF 500 F DOMEKT CF 700 V UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...
  • Page 11 6. Exhaust fan D. Exhaust air 7. Air by-pass damper E. Kitchen hood connection 8. Condensate drain (by-pass – extraction without heat recovery) (the water trap must be installed) UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...

  • Page 12: Installation

    1. Air handling unit 2. Air duct connections 3. Sound attenuator 4. Drain siphon (if provided) 5. Rubber vibration absorber (not included in unit set) 4 Picture UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...
  • Page 13 5b Picture** * Only F type units ** Only R 250 F, R 400 F, R 700 F, S 800 F HW, S 1000 F HW units. UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...
  • Page 14 6. Gasket 2. Wall plug 7. Self tapping screw 3. Hanging bracket 1 8. L-shape bracket 4. Hanging bracket 2 9. Washer M5 DIN9021 5. Bolt M5 UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...

  • Page 15: Duct System Installation

    AHU: outdoor intake air air supplied to the premises air extracted from the premises outdoor exhaust air Fig. 8. Air duct marking UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...
  • Page 16 The kitchen hood with integrated exhaust fan must not be connected to the additional air exhaust duct. Such hood must be connected to a duct sepa- rated from the general ventilation system. UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...

  • Page 17: Condensate Drain Connections

    If the drain line is run through cold spaces, it should be insulated to prevent freezing. A heating cable may be required. UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...

  • Page 18: Water Trap Installation For A Unit Section Mounted On The Suction Side

    RECOMMENDATION: The drainage siphon must be installed in connection with not less size pipe diameter. Any drainage systems must not be connected directly to the municipal sewage system. The conden- sate tray shall be easily accessible for cleaning and disinfection. UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...
  • Page 19 4. Self tapping screw 4,2×13 5. Unit bracket 6. Bottom bracket 7. Screw M4x16 (DIN 7895) 8. Bracket for decorative panel 9. Screw 2.5×16 with cone head UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...
  • Page 20 6. Wall mounting bracket 7. Unit bracket 8. Self tapping screw 4,2×13 9. Bracket for decorative panel 10. Screw 2.5×16 with cone head Dimensions for mounting furniture panel 32.5 32.5 UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...
  • Page 21 4. Screws M4 for hood fixation (4 picture) 4 (×4) 5. Self tapping screws 4,2×13 for adapter fixation (10 picture) 12b Picture. Installation of standard kitchen hood 12c Picture. Installation of kitchen hood 392-12 UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...
  • Page 22 Dimensions for the DOMEKT R 190V / 200V installation space 140 × 4 = 560 13 Picture. Dimensions with standard kitchen hood 140×4 = 560 14 Picture. Dimensions with kitchen hood 392-12 UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...
  • Page 23 When closing unit doors, fixing nuts (7) should be easily tightened by hand. Do not over tighten, since it will damage the doors or casing of the unit. UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...

  • Page 24: Heating Coil Connection

    Replace any panels, which may have been removed and close all access doors, ensuring that the door sealing gaskets have not been damaged. If water heater build in. It is recommended to use PPU made by Komfovent. UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...

  • Page 25: Maintenance

    Filters are one time used. We do not recommend cleaning them. Stop the air handling unit before changing filters. Clogged filters unbalance ventilation system, air handling unit uses more power. UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...
  • Page 26 Close the door after pressure sensor regulating process. Be sure that sensor does not indicate im- purity of clear filters. • Pressure sensors in the air handling units up to size 900 are regulated and set in factory. UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...

  • Page 27: Unit Dimensions

    764 750 598 600 382 139 Right 1146 1130 1020 495 165 325 165 325 155 700 V Left 1146 1130 1020 495 165 325 165 325 155 UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...

  • Page 28: Horizontal Units

    DOMEKT CF (C6) Right 700 1533 1500 246 246 246 246 200 200 200 200 700 H Left 700 1533 1500 246 246 246 246 200 200 200 200 UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...

  • Page 29: Flat Units

    1400 1045 1045 Right 1394 1365 700F Left 1394 1365 Units Domekt S Dimensions, mm Unit DOMEKT S (C5) 650F 237,5 237,5 800F 1005 237,5 237,5 1000F UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...

  • Page 30: Filters

    Domekt S 800 F Compact ePM1 55% (F7) 371×287×46 Domekt S 1000 F Compact ePM1 55% (F7) 558×287×46 * ePM1 55% (F7) class filter is available as an option. UAB KOMFOVENT we reserve the right to make changes without prior notice D_21-03...
  • Page 32 UAB KOMFOVENT PARTNERS TECHNINĖS PRIEŽIŪROS SKYRIUS / SERVICE AND SUPPORT J. PICHLER Gesellschaft m. b. H. www.pichlerluft.at Tel. +370 5 200 8000 service@komfovent.com Ventilair group www.ventilairgroup.com ООО «КОМФОВЕНТ» ACB Airconditioning www.acbairco.be Россия, Москва ул. Выборгская д. 16, REKUVENT s.r.o. www.rekuvent.cz стр.
