Reset Button

You need:
A slim screwdriver (1 or 2mm), paperclip, or similar thin object that can fit into the reset hole.
The following is the default condition for the RESET button on the device. You can program a change to the
behavior of the button if needed. To reset the device:
1. Remove the clear plastic cap.
2. Find the hole labeled RESET. The reset button is recessed.
3. Use the screwdriver or paperclip to press and release the RESET button as follows:
To reboot, press RESET for less than 3 seconds.
To reboot and restore user-defined defaults (if previously set), press RESET for 3 to 29 seconds.
To reboot, restore factory settings, and erase user-defined defaults, press RESET for 30 seconds or
longer.
4. Reattach the plastic cover and tighten to 10.5 lbf.in (12 kgf.cm).
Note: The device reboots when restoring settings.

Power Measurements

Cellular Power Measurements

Note:
Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into the power source
when determining product load.
Maximum Power: The continuous current during maximum data rate with the radio
transmitter/LoRa at maximum power.
Tx Pulse: The average peak current during HSDPA/LTE connection with LoRa at Max power.
Inrush Charge: The total inrush charge at power on.
Voltage Power Down
Mode via
Radio
Command
LTE BAND 7 (2535 Mhz)
37VDC POE 51 mA
57VDC POE 41 mA
WCDMA Band 1 (1922.4 MHz)
37VDC POE 47 mA
®
Conduit IP67 Series 200 Base Station MTCDTIP2 Hardware Guide
Cellular Call Average
Box Measured
Connection Current at
(No Data) Max Power
53 mA 212 mA
42 mA 151 mA
51 mA 218 mA
SPECIFICATIONS AND RELATED INFORMATION
TS Pulse Total Inrush
Average Peak Charge
Current for measured in
HSDPA/ LTE MilliCoulombs
388 mA 1.16 mC
276 mA 1.06 mC
380 mA 1.16 mC
Total Inrush
Charge
DURATION
during
Powerup
(INRUSH
Duration)
8.98 mS
8.0 mS
8.98 mS
