- Page 1 BiPAC 7001 ADSL USB Modem Quick Start Guide...
-
Page 3: Package Contents
This Quick Start Guide Place the Attention Billion BiPAC 7001 ADSL USB Modem Do not use the BiPAC 7001 in high humidity or high temperatures. Avoid using this product and all accessories outdoors. Place the BiPAC 7001 on a stable surface. -
Page 4: The Front Panel
Quick Start Guide The Front Panel ADSL : DATA: transmitting/receiving data USB: The Rear Ports Port the PC LINE when connecting to the ADSL/telephone network. Meaning Lit when successfully connected to an ADSL DSLAM (“linesync”) When this LED is flashing constantly, it indicates the Modem is Lit when the USB port is connected to the PC and working properly Meaning Connect the supplied USB cable to this port when connecting to... - Page 5 Billion BiPAC 7001 ADSL USB Modem Connecting Your ADSL USB Modem 1. To Connect ADSL telephone cable to the LINE RJ-11 jack, connect the USB cable to the USB port and connect the other end to the PC 2. Make sure the USB and ADSL LEDs are lit steadily and lit.
-
Page 6: Information From Isp
Bridged RFC1483 Routed IPoA Installing Billion ADSL USB Modem To Connect ADSL telephone cable to the LINE RJ-11 jack, connect the USB cable to the USB port and connect the other end to the PC VPI/VCI, VC-based/LLC-based multiplexing, Username, Password, Service Name, and... -
Page 7: For Windows
1. Insert the CD into your computer’s CD Rom drive. This is the hi-speed modem installation CD, Click “setup. exe” to continue.”. 2. Choose service provider from the list below and then click “Next” to continue. Billion BiPAC 7001 ADSL USB Modem... - Page 8 Quick Start Guide 3. Then click “Next”. 4. Please plug USB cable into ADSL USB Modem.
- Page 9 Billion BiPAC 7001 ADSL USB Modem 5. Select “Yes, reboot the computer now”, than close the windows. 6. After restart the PC, window will show congratulation message and user can enjoying Internet.
- Page 10 Quick Start Guide 7. After Billion ADSL USB Modem driver is successfully installed, you will see these 2 icons on your desktop.
- Page 11 1. Start Windows. Then insert the installation CD into the CD-ROM drive. In next window, click the driver installer. 2. Then, click “Next”. 3. Input the user name and password of your Mac system. (MAC OS X only) Billion BiPAC 7001 ADSL USB Modem...
- Page 12 Quick Start Guide 4. The “License Agreement” screen will appear, then click “Accept”.. 5. To click the type of setup you prefer, then click Next >.
-
Page 13: For Linux
Billion BiPAC 7001 ADSL USB Modem 6. Select “Restart now”, than close the windows. For Linux: For Linux installation instructions, please refer to the text file provided with your Linux driver’s package. - Page 14 Quick Start Guide Configuring Billion ADSL USB Modem (For Windows) 1. Click Billion ADSL USB Modem icon in the Control Panel or DSL Status icon on the desktop. The status of ADSL connection will be displayed. 2. Press , the following widow will appear. (To show DSL data include Package...
-
Page 15: Product Support And Contact Information
For Billion ADSL USB WAN Adapter: 1. Click Billion Dial-up PPP connection icon on the desktop. The following window should appear. Enter the “Username” and “Password” provided by your ISP. Let the Phone number field be blank. Click Connect and get ready to surf the Internet! Product Support and Contact Information Most problems can be solved by referring to the Troubleshooting section in the User’s Manual.
