Page 1: Quick Start Guide
BIPAC-221 USB ISDN TA with 2 Analog Ports Quick Start Guide This product is designed for the ISDN with Basic Rate Interface. -
Page 2: Package Contents
Package Contents • One external USB ISDN TA with 2 analog ports • One installation CD with drivers and utility software • One CD with bundled application software programs (optional) • One RJ-45 ISDN cable • One USB cable • One power adapter •... -
Page 3: For Windows 98
Billion BIPAC-221 Installing the BIPAC-221 Power jack POWER 1. Connect the external power adapter to the power jack. All the LEDs light and then go off one by one, except that the PWR LED will still light. 2. Connect your ISDN line to the ISDN S 3. - Page 4 2. In the next window, select “Search for the best driver for your device” and click “Next >”. 3. Insert the installation CD into the CD-ROM drive and check “CD-ROM drive” in the next window. 4. Continue through the Wizard, clicking the “Next >” buttons.
-
Page 5: For Windows Me
Billion BIPAC-221 5. If you are prompted to restart the computer after Windows finishes installing the driver, press “Yes”. For Windows Me: 1. Start Windows. After the opening banner, Windows will tell you that the new device has been detected. Select “Specify the location of the driver”... - Page 6 2. In next window, select “Search for the best driver for your device”. Insert the installation CD into the CD-ROM drive and check “Removable Media”. Click the “Next >” button. 3. Continue through the Wizard, clicking “Next >” at the following screens.
-
Page 7: For Windows 2000
Billion BIPAC-221 For Windows 2000: 1. Start Windows. After the opening banner, Windows will tell you that the new device has been detected. Click “Next>”. 2. In next window, select “Search for a suitable driver for my device”. Click “Next>”. 3. - Page 8 Quick Start Guide 4. Click “Next>” to install the driver. When the following windows titled “Digital Signature Not Found” appear, press “Yes” to continue the installation.
-
Page 9: For Windows Xp
Billion BIPAC-221 5. Press “Finish” to end the installation. For Windows XP: 1. Start Windows. After the opening banner, Windows will tell you that the new device has been detected. Select “Install the software automatically”. Insert the installation CD into the CD-ROM drive and click “Next >”. 2. - Page 10 Quick Start Guide 3. Click “Continue Anyway” when the following “Hardware Installation” windows appear.
- Page 11 Billion BIPAC-221 4. Press “Finish” to end the installation. ISDN Utility and Diagnostic Program The ISDN Utility includes helpful programs for the USB ISDN TA, such as a diagnostic program, an uninstallation program, and an on-line manual. After Windows installs the driver of your ISDN TA, the ISDN Utility may be installed automatically.
- Page 12 4. Press “Loopback Test” to begin the diagnostic procedure. It will make a call from the B1 channel that returns through the B2 channel. The D and B channels will be tested for line integrity. Uninstalling BIPAC-221 If you decide to permanently remove the driver and utility of the USB ISDN TA from your system, you must run the uninstallation program from the ISDN Utility program group as follows:...
-
Page 13: Product Support
Billion BIPAC-221 Product Support If you have any problem with the USB ISDN TA, please contact the dealer where you bought this product. If you have any other question, you can contact Billion Electric Co., Ltd. directly at the following email address: You can also download upgraded driver or software utilities for free from Billion’s web site at For more detailed instructions on configuring and...
