- Page 1 BIPAC 5102 / 5102S / 5102G (802.11g) ADSL2+ Modem/Router Quick Start Guide...
-
Page 3: Package Contents
CD-ROM containing the on-line manual RJ-11 ADSL/telephone Cable Ethernet (CAT-5 LAN) Cable AC-DC power adapter (12VDC, 1A) : BIPAC 5102 / 5102G AC-AC power adapter (9VAC, 1A) : BIPAC 5102S This Quick Start Guide Do not use the ADSL2+ Modem/Router in high humidity or high temperatures. -
Page 4: The Front Leds
Quick Start Guide The Front LEDs BIPAC 5102 BIPAC 5102S BIPAC 5102G PPP : ADSL: LAN Port: WLAN : (5102G only) SYS : PWR : Meaning Lit steady when there is a PPPoA / PPPoE connection. Lit when successfully connected to an ADSL DSLAM (“linesync”). -
Page 5: The Rear Ports
RESET (RJ-45 connector) ADSL (LINE) Billion BIPAC 5102 / 5102S / 5102G ADSL2+ Modem/Router Connect the supplied power adapter to this jack. After the device is powered on, press it to reset the device or restore to factory default settings. - Page 6 Quick Start Guide Connecting BIPAC 5102 1. Connect the Router to a LAN (Local Area Network) and the ADSL/telephone (LINE) network. 2. Power on the device. 3. Make sure the PWR and SYS LEDs are lit steadily and that the relevant LAN LED is lit.
- Page 7 Billion BIPAC 5102 / 5102S / 5102G ADSL2+ Modem/Router Connecting BIPAC 5102S 1. Connect the Router to a LAN (Local Area Network) and the ADSL/telephone (LINE) network. 2. Power on the device. 3. Make sure the PWR and SYS LEDs are lit steadily and that the relevant LAN LED is lit.
- Page 8 Quick Start Guide Connecting BIPAC 5102G 1. Connect the Router to a LAN (Local Area Network) and the ADSL/telephone (LINE) network. 2. Power on the device. 3. Make sure the PWR, SYS, and WLAN LEDs are lit steadily and that the relevant LAN LED is...
-
Page 9: Configuring Pc In Windows Xp
4. Select Internet Protocol (TCP/IP) and click Properties. 5. Select the Obtain an IP address automatically and the Obtain DNS server address automatically radio buttons. 6. Click OK to finish the configuration. Billion BIPAC 5102 / 5102S / 5102G ADSL2+ Modem/Router... -
Page 10: Configuring Pc In Windows 2000
Quick Start Guide Configuring PC in Windows 2000 Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4. -
Page 11: Configuring Pc In Windows 98/Me
3. Select the Obtain an IP address automatically radio button. 4. Then select the DNS Configuration tab. 5. Select the Disable DNS radio button and click OK to finish the configuration. Billion BIPAC 5102 / 5102S / 5102G ADSL2+ Modem/Router... - Page 12 Quick Start Guide Configuring PC in Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK.
- Page 13 2. A username and password window will appear. The default username and password are admin and admin. Press OK to proceed. 3. You will get a status report on web page. Billion BIPAC 5102 / 5102S / 5102G ADSL2+ Modem/Router in the browser’s...
-
Page 14: Product Support And Contact Information
Quick Start Guide Verifying Your Local Network Connection with the Device To see if this ADSL Router is visible on the local network, go to Start / Run. In the Run dialog box, type “ping 192.168.1.254” then press OK. A command prompt window will pop out.
