User Manual
BiPAC 7001
ADSL USB Modem
Billion's BiPAC 7001 complies with ADSL standards and supports
downstream rate up to 8 Mbps. With its user-friendly installation utility
and plug-and-play USB interface, the modem can be easily installed
on a desktop PC or notebook PC without opening the case of the
computer or adding any network interface card (NIC). Users can enjoy
ADSL services and broadband multimedia applications such as
interactive gaming, video streaming and real-time audio much easier
and faster than ever. The BiPAC 7001 also supports many different
kinds of operating systems such as Windows, Mac, and Linux for
more compatibility.
• High-speed Internet Access with ADSL
• Multi-protocol to Establish a Connection
with ISP
• User-friendly Installation Utility
• USB Bus-powered and Plug-and-Play
Feature & Specification
ADSL Compliance
•
Compliant with ADSL Standard
- Full-rate ANSI T1.413 Issue 2
- G.dmt (ITU G.992.1)
- G.lite (ITU G.992.2)
- G.hs (ITU G.994.1)
- ADSL over ISDN/U-R2
ATM and PPP Protocols
•
ATM Adaptation Layer Type 5 (AAL5)
•
Multiple Protocol over AAL5 (RFC 2684, formerly
RFC 1483)
•
Bridged or routed encapsulation
•
VC and LLC based multiplexing
•
PPP over Ethernet (PPPoE)
•
PPP over ATM (RFC 2364)
•
OAM F4/F5 loopback
Features
•
Downstream data rate up to 8 Mbps, upstream up to
1 Mbps
•
Interoperable with major CO DSLAM equipment
vendors
•
USB bus-powered, no external power supply is
required
•
Compliant with USB specification 1.1
•
Software upgradable
Billion Electric Co., Ltd.
8F, No.192, Sec.2, Chung Hsing Road,
Hsin Tien City, Taipei Hsien, Taiwan
www.billion.com
TEL : +886-2-2914-5665
FAX : +866-2-2918-6731,+886-2-2918-2895
E-mail : sales@billion.com
• Supports Windows 98/98SE/Me/2000/XP,
Mac OS 9.2.1/10.1/10.2.3 ,
Linux RedHat 7.1/8.0/9.0
• Ideal for Residential Users
Hardware Specification
Physical Interface
•
WAN : ADSL port
•
USB : Comply to USB v1.1
Physical Specification
•
Dimensions : 5.20" x 3.70" x 1.38"
(132mm x 94mm x 35mm)
Operating Environment
•
Operating temperature: 0 ~ 40ºC
•
Storage temperature: -20 ~ 70 ºC
•
Humidity: 20 ~ 95% non-condensing
OS Support
•
Windows: 98/98SE/Me/2000/XP,
•
Mac OS: 9.2.1/10.1/10.2.3
•
Linux OS: RedHat 7.1 (kernels 2.4.2-2)
RedHat 8.0 (kernel 2.4.18-14)
RedHat 9.0 (kernel 2.4.20-8)
Application Diagram
Specifications are subject to changes without notice.
