- Page 1 BIPAC-7000 ADSL USB Modem Quick Start Guide...
-
Page 2: Package Contents
If your ISP provides PPPoE or PPPoA connection method, please select “Billion ADSL USB WAN Adapter” to install driver. If your ISP provides RFC1483 Bridged or Routed or IPoA, please select “Billion ADSL USB LAN Adapter” to install driver. -
Page 3: Installing Billion Adsl Usb Modem
Domain Name System (DNS) IP address (it is fixed IP address). Installing Billion ADSL USB Modem To Connect ADSL telephone cable to the LINE RJ-11 jack, connect the USB cable to the USB port and connect the other end to the PC. -
Page 4: For Windows Xp
2. Insert the installation CD into the CD-ROM drive and select “Include this location in the search”. Click “Browse” to specify the driver directory such as F:\Driver\LAN for installing Billion ADSL USB LAN Adapter or F:\Driver\WAN for installing Billion ADSL USB WAN Adapter. - Page 5 When windows Installation” appears, click “Continue Anyway” to go on. Then, click “Finish”. 5. After Billion ADSL USB Modem driver is successfully installed, the Status Task Bar will appear on the System Tray. titled “Hardware Installation” Quick Start Guide “Software...
-
Page 6: For Windows 2000
3. Click “Browse..”. In the Locate File window, specify the driver directory such as F:\Driver\LAN\CxtCAFEU for installing Billion ADSL USB LAN Adapter or F:\Driver\WAN\CxtCAFEU for installing Billion ADSL USB WAN Adapter. (Please refer Information from ISP section for more details.) Click “Open” and then “Next>“ to continue. - Page 7 4. When windows titled “Digital Signature Not Found” appears, click “Yes” to continue the installation. 5. Press “Finish”. 6. After Billion ADSL USB Modem’s driver is successfully installed, the Status Task Bar will appear on the System Tray. Quick Start Guide...
-
Page 8: For Windows Me
2. Insert the installation CD into the CD-ROM drive and check “Specify a location”. Click “Browse…” to specify the driver directory such as F:\Driver\LAN for installing Billion ADSL USB LAN Adapter or F:\Driver\WAN for installing Billion ADSL USB WAN Adapter. - Page 9 3. Continuing through the Wizard, Windows will start copying files to your system. Then, click “Finish”. 4. After Billion ADSL USB Modem driver is successfully installed, the Status Task Bar will appear on the System Tray. Quick Start Guide...
-
Page 10: For Windows 98
3. Insert the installation CD into the CD-ROM drive and check “Specify a location”. Click “Browse…” to specify the driver directory such as F:\Driver\LAN for installing Billion ADSL USB LAN Adapter or F:\Driver\WAN for installing Billion ADSL USB WAN Adapter. - Page 11 Quick Start Guide 4. Continuing through the Wizard, click the “Next >” button. Windows will start copying files to your system. 5. Then, click “Finish”.
- Page 12 Billion BIPAC-7000 ADSL USB Modem 6. When Billion ADSL USB Modem driver is successfully installed, the Status Task Bar will appear on the System Tray. For Mac OS 9: If you connect the ADSL Modem/Router through USB port, for the first time the USB cable is connected to the PC, the host PC OS will automatically detect the device.
- Page 13 3. Click “Restart” to end the installation. For Mac OS X: 1. Insert the installation CD into the CD-ROM drive, click the driver installer. Input the user name and password of your Mac system. 3. Click “Continue”. Quick Start Guide...
- Page 14 Billion BIPAC-7000 ADSL USB Modem Select a destination to install the driver, choose Mac X. Click “Continue”. 6. Click “Continue Installation” to end the installation.
- Page 15 #rpm –i BIPAC-7000-REDHAT-7.1.i386.rpm (Redhat 7.2) #rpm –i BIPAC-7000-REDHAT-7.2.i386.rpm (Redhat 8.0) #rpm –i BIPAC-7000-REDHAT-8.0.i386.rpm. (Redhat 9.0) #rpm –i BIPAC-7000- REDHAT-9.0.i386.rpm. 2. Launch the driver #cd /usr/local/e2 #insmod e2.o #ifconfig hsb0 up(Note: run this command after the READY LED blinks) #dhcpcd hsb0 (Note: run this command after the READY LED blinks) 3.
- Page 16 Billion BIPAC-7000 ADSL USB Modem Configuring Billion ADSL USB Modem (For Windows) 1. Click Billion ADSL USB Modem icon in the Control Panel or ADSL Configuration icon on the desktop. The status of ADSL connection will be displayed. 2. Press [Alt]+[P] on keyboard, the following widow will appear.
- Page 17 (For Mac OS 9/X and Linux Redhat 7.1/7.2) The ADSL USB Modem uses “Emulate USB port to Ethernet” technology to emulate USB port to Ethernet port for Mac and Linux system. The ADSL USB Modem can be configured with your web browser. The default IP address of the ADSL USB Modem is 192.168.1.254 and subnet mask is 255.255.255.0.
- Page 18 Billion BIPAC-7000 ADSL USB Modem Open your Web browser to begin surfing the Internet. For more detailed instructions on configuring and using the product, please refer to the on-line manual.
- Page 19 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Right–click on Local Area Connection that is using the Billion ADSL USB LAN Adapter and then click “Properties”. 3. Select Internet Protocol (TCP/IP). Then click “Properties”.
- Page 20 Billion BIPAC-7000 ADSL USB Modem Select Use the following DNS server addresses, and then enter the provided DNS server IP address. For Billion ADSL USB WAN Adapter: 1. Click ADSL Easy Dialup icon on the desktop. The following window should appear. Enter the “Username” and “Password” provided by your ISP.
-
Page 21: Product Support And Contact Information
User’s Manual. If you cannot resolve the problem with the Troubleshooting chapter, please contact the dealer where you purchased this product. Contact Billion AUSTRALIA http://www.billion.com.au Hotline: 1300 139 159, 7 days a week. ©2003 Billion Electric Co, PC Range P/L. All Rights Reserved. WORLDWIDE http://www.billion.com...
