Summary of Contents for Billion BIPAC-7402
- Page 1 All manuals and user guides at all-guides.com BIPAC- 7402 ADSL Modem/Router Features >> Features >> VPN with 3DES Accelerator, Features >> Features >> QoS (Quality of Service) & 4- port Switch!! Quick Start Guide...
-
Page 2: Package Contents
Having Internet access will not be far away from this point of time. This router, Billion 7402, has been customised for New Zealand users. That is, its factory default profile is pre-configured for New Zealand. - Page 3 All manuals and user guides at all-guides.com Billion 7402 ADSL Modem/Router WARNING! The grant of a Telepermit for any item of terminal equipment indicates only that Telecom has accepted that the item complies with minimum conditions for connection to its network. It indicates no endorsement of the product by Telecom, nor does it provide any sort of warranty.
- Page 4 All manuals and user guides at all-guides.com Billion 7402 ADSL Modem/Router To know about your ADSL Modem/Router… The Front Panel LEDs of Billion 7402 Meaning Lit steady when there is a PPPoA / PPPoE connection. PPP/MAIL Lit and flashed periodically when there is email in the Inbox.
- Page 5 All manuals and user guides at all-guides.com Billion 7402 ADSL Modem/Router Please follow Billion’s READY? & GO! Program to complete the setup of the router and enjoy the high speed of Internet!! READY? [Do you have the following installed on your PC?]...
- Page 6 All manuals and user guides at all-guides.com Billion 7402 ADSL Modem/Router The Rear Ports of 7402 LINE (3.1) Plug in RJ-11-A cable to this LINE port and another end of cable to the MODEM port on the [RJ-11 A- SPLITTER.
- Page 7 All manuals and user guides at all-guides.com Billion 7402 ADSL Modem/Router [Software Chapter] 2.2.1 Connection Mode LAN (Ethernet) port users: Please follow the “Configuring the Network Properties on a PC” section (Procedure 2.2.2) on the bottom of this page to modify the network settings.
- Page 8 All manuals and user guides at all-guides.com Billion 7402 ADSL Modem/Router Windows 95/98/Me users Click Start and go to Settings Control Panel Network. Select Internet Protocol (TCP/IP) [Name of Your Network Card] and Click Properties. Select the IP Address tab. In...
- Page 9 All manuals and user guides at all-guides.com Billion 7402 ADSL Modem/Router Windows NT 4.0 users Click Start and go to Settings Control Panel Network. Select Internet Protocol (TCP/IP) [Name of Your Network Card] and Click Properties. Select the Obtain an IP...
- Page 10 All manuals and user guides at all-guides.com Billion 7402 ADSL Modem/Router Snapshot of a Successful Connection A command prompt window will pop out. If your ping is successful which means your local network is able to reach to the device, then the command prompt window will close up automatically.
- Page 11 All manuals and user guides at all-guides.com Billion 7402 ADSL Modem/Router Click Quick Start on the pane at the left-hand-side. Check the Encapsulation is PPPoA and Values of Virtual Circuit ID, VPI & VCI are 0 and 100 respectively. Please refer to the figure on the right-hand-side.
- Page 12 All manuals and user guides at all-guides.com Billion 7402 ADSL Modem/Router A “Successful” message should appear. Click SAVE CONFIG and then Apply to save settings you have made permanently. “Save Config FLASH Successful” message should appear. Note: You could still connect to...
- Page 13 All manuals and user guides at all-guides.com Billion 7402 ADSL Modem/Router Not Connected??? Click F5 key to return to the Home Page of Router and check the WAN table and see if you have the figure shown on the right- hand-side.
