SOFTWARE SETTING

You can program various parameters with Programming Unit, model: PU-2x. For detailed explanations, please refer to the
Operation Manual for Model PU-2x (EM-9255), Section B.
In the Programming Unit, specifying GROUP No. and ITEM No. (each 2 digits) determines which item is to be changed.
GROUP 00 is for system functions: software version information, error report, etc, which are common to all pulse transmitter
series.
GROUP 01 includes all necessary parameters for pulse transmitters. The table below indicates which items are related to this
unit.
You can even change those parameters which are not related to this unit, however, it may destroy some other parameters. Be
sure to use only the items in the table.
ITEM
Model indication
Maintenance switch
Tag No.
Input frequency monitor
Input frequency monitor
Input counter value
Output zero frequency
Output span frequency
Frequency unit
Input zero frequency
Input span frequency
Cutout time
Sampling time
Output frequency limit
GROUP No. ITEM No.
01 00
01 01
01 02 user's TAG entry
01 05 measured input %
01 06
01 07
01 08
01 09
01 11
01 12
01 13
01 20
01 21
01 33
DISPLAY CONTENTS
JPRD
maintenance sw Switching to PROGRAM mode which allows parameter change.
User's Tag name entry and monitor
Input 1 frequency in %
measured freq Input 1 frequency in in Hz
input counts Total number of input pulses since the power is turned on.
output zero freq Set to 0. DO NOT change.
output span freq Numerator of scaling factor
unit frequency Frequency unit used in programming
input zero freq Set to 0. DO NOT change.
input span freq Denominator of scaling factor
drop out timer DO NOT change.
sampling timer Sampling time
output freq limit Output frequency limit
