STATUS INDICATOR LED
The CPU status is indicated by different blinking patterns of the front
indicator LED. 1 pattern cycle is divided in 16 ON or OFF periods, each of
which lasts for 320 millisec.
In the figure to the right,
it is ON. The ON-OFF pattern changes from the left end to the right in 320
millisec. duration.
There are more of these patterns which are not shown here, however, when
the last one shown in the figure to the right or some other pattern is
indicated, contact M-System.
The anomaly report is available also on the display of the Programming
Unit. Refer to its manual for detailed information.
HARDWARE SETTING & CALIBRATION
SW1 & 2 FUNCTIONS (SW1: Input 2, SW2: Input 1, SW1-3 and SW2-3 are used commonly to both inputs.)
SWITCH
NO.
SW FUNCTION
SW1,2 – 1
ON with dry contact input (model suffix: A)
2
ON with 2-wire current pulse input (model suffix: H)
3
SW1–3: Adjustable range of sensitivity level for V
SW2–3: Adjustable range of sensitivity level for V
Refer to the section "SENSITIVITY ADJUSTMENT".
4
Output logic
5
Noise filter Type 1 (ON: with, OFF: without)
6
Noise filter Type 2 (ON: with, OFF: without)
7
Attenuator for input signal (ON: with, OFF: without)
Input voltage is attenuated to half the original amplitude with this switch ON.
(one-third for the model number suffix code A.)
8
Input pulse sensing method (ON: DC coupled, OFF: capacitor coupled)
Turn this switch off with a 10V or greater offset.
means that the light is OFF, while
Sensor Excitation Adj.
SW2
1
O
2
N
3
4
5
6
7
8
Set each switch according
to the table below.
Input Monitor LED PL1
Input Monitor LED PL2
INPUT MODEL SUFFIX CODE
NORMAL BLINKING PATTERNS
Monitor mode, normal input status
means that
Monitor mode, cutout status
Program mode
ABNORMAL BLINKING PATTERNS
Parameters are destroyed or functioning in default values.
Parameters are destroyed and impossible to recover.
1
2
3
4
5
6
7
8
Set each switch according
to the table below.
Not Used
Not Used
Sensitivity Adj. (V
(front cover open)
Sensitivity Adj. (V
(ON: 0 – 10V, OFF: 0 – 5V)
L
(ON: 0 – 10V, OFF: 0 – 5V)
L
*Set to ON with excitation voltage ≥24V.
SW1
O
N
)
H
)
L
A
B
C
ON
OFF
OFF
OFF
OFF
OFF
ON or OFF
OFF
(required level)
ON or OFF
ON or OFF according to the noise level. Refer
to the tables below for the max. frequency
which can pass through the filter.
OFF *
OFF *
OFF
ON
P. 4 / 8
JPSM
D
H
OFF
OFF
OFF
ON
ON or OFF
OFF
(required
level)
OFF *
OFF
EM-1689 Rev.5
