AquaPrep 055
The fuses used in the AquaPrep must be identical in type and rating to that specified.
Use of other fuses could result in electrical shock and/or damage to the analyzer.
c Insert appropriate fuse(s) for the input power source. Refer to the chart below for the
appropriate fuse rating.
7. Insert fuse block and cover assembly into input power connector and snap it into place.
Once the fuse block and cover assembly are in place, the position of the indicator pin
shows the input power selected.
Oct 09
Power Source
100-120 VAC
2.0 Amp (slow-blow)
220-240 VAC
1.0 Amp (slow-blow)
Installing the AquaPrep
Fuse
2-5
