Assembly

WARNING
Do not plug in your carpet cleaner until you are familiar with all instructions and operating procedures.
In step 3, you will need to use a Phillips-head screwdriver.
1
First, insert the Upper
Handle at the top of the
base until you hear a "click".
3
Using a Phillips-head
screwdriver, secure the
Carry Handle with the screw
that's taped to the Upper
Handle.
2
click
4
Wrap the cable around the
Carry Handle and Cable
Quick Release.
Next, align the Carry Handle
with the slots on either side
of the base (behind the
Power Switch and Cleaning
Mode Switch). The Carry
Handle will "click" into place.
IMPORTANT: Do NOT put
the Clean Water Tank on the
machine until step 5.
5
Side
View
At the bottom of the
Upper Handle, align the
Clean Water Tank with
the grooves and slide
the tank into place.
