- Page 1 D1054S INSTRUCTION & SAFETY MANUAL SIL 2 Repeater Power Supply and Trip Amplifiers Din-Rail Model D1054S D1054 - SIL 2 Repeater Power Supply and Trip Amplifiers ISM0067-18...
-
Page 2: Technical Data
Characteristics General Description: The single channel DIN Rail Repeater Power Supply and Trip Amplifier D1054S, provides a fully floating dc supply for energizing conventional 2 wires 4-20 mA transmitters, or separately powered 3, 4 wires 4-20, 0-20 mA transmitters located in Hazardous Area, and repeats the current in floating circuit to drive a Safe Area load. Output signal can be direct or reverse. - Page 3 Ordering information Power Bus and DIN-Rail accessories: Model: D1054S DIN rail anchor MCHP065 DIN rail stopper MOR016 Terminal block male MOR017 Terminal block female MOR022 Power Bus enclosure Operating parameters are programmable by the GM Pocket Portable Configurator PPC1090 or via RS-232 serial line with PPC1092 Adapter and SWC1090 Configurator software.
-
Page 4: Parameters Table
Parameters Table In the system safety analysis, always check the Hazardous Area/Hazardous Locations devices to conform with the related system documentation, if the device is Intrinsically Safe check its suitability for the Hazardous Area/Hazardous Locations and gas group encountered and that its maximum allowable voltage, current, power (Ui/Vmax, Ii/Imax, Pi/Pi) are not exceeded by the safety parameters (Uo/Voc, Io/Isc, Po/Po) of the D1054 Associated Apparatus connected to it. -
Page 5: Function Diagram
CLASS II, DIVISION 1, GROUPS E, F, G, CLASS III, DIVISION 1, GROUPS A, B, C, D T-Code T4, CLASS I, ZONE 2, GROUP IIC T4 CLASS I, ZONE 0, GROUP IIC MODEL D1054S Supply 12-24 Vdc 2 Wire Tx... - Page 6 Safety Function and Failure behavior: D1054S is considered to be operating in Low Demand mode, as a Type B module, having Hardware Fault Tolerance (HFT) = 0. The failure behaviour of module (only the 4 - 20 mA current output configuration is used for safety application) is described from the following definitions: ...
- Page 7 Safety Function and Failure behavior: D1054S is considered to be operating in Low Demand mode, as a Type B module, having Hardware Fault Tolerance (HFT) = 0. The failure behaviour of module (only the 4 - 20 mA current output configuration is used for safety application) is described from the following definitions: ...
- Page 8 Safety Function and Failure behavior: D1054S is considered to be operating in Low Demand mode, as a Type B module, having Hardware Fault Tolerance (HFT) = 0. The failure behaviour of module (only Alarm A and Alarm B trip amplifiers is used for safety application) is described from the following definitions: ...
- Page 9 Safety Function and Failure behavior: D1054S is considered to be operating in Low Demand mode, as a Type B module, having Hardware Fault Tolerance (HFT) = 0. The failure behaviour of module (only Alarm A and Alarm B trip amplifiers is used for safety application) is described from the following definitions: ...
-
Page 10: Installation
Restore the loop to full operation. Remove the bypass from the Safety PLC or restore normal operation. Test for D1054S (for each alarm trip amplifier with relay output): Proof test 1B (to detect approximately 50 % of possible Dangerous Undetected failures) Steps Action Bypass the Safety PLC or take other appropriate action to avoid a false trip. -
Page 11: Operation
Warning D1054 is an isolated Intrinsically Safe Associated Apparatus installed into standard EN50022 T35 DIN Rail located in Safe Area/ Non Hazardous Locations or Zone 2, Group IIC, Temperature Classification T4, Class I, Division 2, Groups A, B, C, D, Temperature Code T4 and Class I, Zone 2, Group IIC, IIB, IIA Temperature Code T4 Hazardous Area/Hazardous Locations (according to EN/IEC60079-15, FM Class No. - Page 12 D1054S [1 Level Menu] Displays Model D1054S single channel smart repeater power supply plus trip amplifier. Press “Enter” key to second level menu. [2 Level Menu] Displays the parameters configuration menu. Press “Enter” key to configure the functional parameters, press the “Select” key to the next menu level item or “Up”...
- Page 13 B Ope [4 Level Menu] Displays the functionality of alarm in burnout condition (A or B) configuration. Press “Enter” to set the burnout alarm condition, press the “Select” key to the next menu level item or “Up” key to return to third level. If you pressed “Enter” key, you can choose between 4 different alarm burnout conditions; press “Select” key to change the type and then the “Enter”...
