HTU-C using Narrowband/Wideband for Litespan Installation and Maintenance Practice

Terminal Modes Screen

The Terminal Modes screen in
Update and Real Time Update. Press "
CIRCUIT ID:
MANUAL UPDATE MODE:
* You can print or log screens
* No text is highlighted
* "3 SPACES TO UPDATE" appears at the top of each screen,
reminding you to press 3 spacebars to update the screen
* There is a delay between screen changes & updates
* After 30 min. of no interaction, a new baud rate search is begun
* Ignores input until screen is finished printing.
REAL-TIME UPDATE MODE:
* Faster of the two modes
* You cannot print screens to a log file
* Highlighting is enabled
* Recommended for daily operation
26
Figure 17 defines the two different terminal modes, Manual
" to toggle between the two terminal modes.
T
TERMINAL MODES MENU
Press "T" to toggle between the terminal modes.
Press "M" to return to the main menu.

Figure 17. Terminal Modes Screen

MM/DD/YY hh:mm:ss
61247002L1-5A
