Unit Information Screen

The ADTRAN Unit Information screen is illustrated in
CLEI code, and manufacturing date for every unit in the HDSL circuit.
CIRCUIT ID:
--------------------- For Information or Technical Support --------------------
Support Hours ( Normal 7am - 7pm CST, Emergency 7 days x 24 hours )
Phone: 800.726.8663 / 888.873.HDSL
-------------------------------------------------------------------------------
HTU-C INFORMATION
----------------------
S/N : A6026223
CLEI: SLL7AAAAA
MANF: 10/07

Loopback Options Menu

The HDSL loopback options menu is illustrated in
loopbacks using these screens. Refer to
loopback information.
CIRCUIT ID:
61247002L1-5A
901 Explorer Boulevard
Huntsville, Alabama 35806-2807
Press "M" to view Main Menu.

Figure 9. Unit Information Screen

"Appendix A, HDSL Loopbacks"
LOOPBACK OPTIONS
_____
|HTU-C|
| |
--->|-----|<=================================>|-----|<---
| |
NET | |
| |
<---|-----|<=================================>|-----|--->
| |
|_____|
1) LOOPBACK TO NETWORK
2) LOOPBACK TO CUSTOMER AT HTU-C = INACTIVE
3) LOOPBACK TO NETWORK
4) LOOPBACK TO CUSTOMER AT HTU-R = INACTIVE
Press corresponding number to toggle loopback option.
Press "M" to return to the Main Menu

Figure 10. Loopback Options Menu

Figure 9. The screen lists serial number,
ADTRAN
Fax: 256.963.6217 Internet: www.adtran.com
HTU-R INFORMATION
--------------------
S/N : PA52D0891
CLEI: T1I3AAXAAA
MANF: 10/07
Figure 10. The user can terminate or evoke
_____
|HTU-R|
LP1 |
|
|
LP2 |
|
|_____|
AT HTU-C = INACTIVE
AT HTU-R = INACTIVE
Menu Descriptions
MM/DD/YY hh:mm:ss
for detailed HDSL
MM/DD/YY hh:mm:ss
|
|
| CUST
|
|
19
