An indication of pair reversal (if present) appears at the bottom of the first key column. Status
and configuration information for the DS1 and DSX-1 signals are located in the center of the
screen near the bottom.
items.
Table 8. Status and Configuration Key Definitions
Indicator
FRAME
CODE
LBO
NIU
BPV
ES
SES
UAS
Alarms
A measure of signal quality (current/minimum/maximum) for each HDSL loop is displayed on
the Current System Status Screen. The noise margin is measure in dB above the 10
Table 9 describes the noise margin quality levels and their indicators.
Margin (in dB)
<0
0–2
>2
61247002L1-5A
Table 8 gives the definitions of the status and configuration key
Definition
T1 framing format selected
T1 line coded selected
Line build-out selected (for DSX-1), Customer signal of 0 or –15 dB
(for DS1)
Network interface unit enabled
Bipolar violations detected (DSX-1 and DS1)
Errored seconds (DSX-1 and DS1)
Severely errored seconds (DSX-1 and DS1)
Unavailable seconds (DSX-1 and DS1)
Lists current alarm condition status
Table 9. Noise Margin Quality
LED Color
Yellow
Green
Red
Menu Descriptions
–7 BER.
Loop Quality
Poor
Marginal
Good
