From the ADTRAN HDSL4 Main Menu (Figure 6),
the following screens can be accessed.
1. HDSL4 Unit Information
2. Provisioning
3. Span Status
4. Loopbacks and Test
5. Performance History
6. Scratch Pad, Ckt ID, Time/Date
Circuit ID:
C C C C C ircuit ID:
--------------------- For Information or Technical Support ---------------------
Support Hours ( Normal 7am - 7pm CST, Emergency 7 days x 24 hours )
Phone: 800.726.8663 / 888.873.HDSL
--------------------------------------------------------------------------------
8
Adtran HDSL4 Main Menu
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Selection:
Figure 6. HDSL4 Main Menu Screen
Press ESC to return to previous menu
ADTRAN
901 Explorer Boulevard
Huntsville, Alabama 35806-2807
ADTN H4TU-C
P/N: 1222401L1
S/N: 123456789
CLEI: T1L5TWPCAA
Manf: 01/01/2000
Ver: 24
1 A00000
ADTN H4R1
P/N: 1221445L1
S/N: BB50A8343
CLEI: T1R5YP3DAA
Manf: 02/12/2002
Ver: 21
1 A00001
Figure 7. Unit Information Screen
7. Terminal Modes
8. Alarm History
9. Event History
10. System PM/Screen Report
11. Virtual Terminal Control
The Unit Information screen (Figure 7) provides
detailed product information on each component in
the HDSL4 circuit.
