Micromeritics ACCUPYC II 1345 Operator's Manual page 61

Sample Files
Field or Button
Cup mass * [text box]
Geometry ** [button]
Material Properties
[button]
Operator [text box]
Sample [text box]
Sample cup *
[drop-down box]
Sample mass
[text box]
Submitter [text box]
AccuPyc II 1345 Operator Manual
134-42851-01 (Rev -) — Not Released
Description
Enter the cup mass.
Enter material properties when using the FoamPyc Method.
User Computed. Select to enter the geometric volume and when
using Correction using cell dimensions selection, the Active Area.
Active Area is the total geometric surface area of the sample -
excluding any sides that contain a skin.
Compute. Select the shape of the sample and enter the dimensions.
Number of Pieces. The number of pieces making up the sample.
See Material Parameters on page 4 -
Enter operator identification information. This field label may have
been renamed or may not display if modified in Options > Sample
Defaults.
Enter a sample description.
Select a sample cup file from the drop-down list or click
and save a new file for sample cup properties. See
page 4 - 5.
Enter the sample mass.
Enter submitter identification information. This text box may have been
renamed or may not display if modified in Options > Sample
Defaults.
Sample Files
6.
Edit to create
Sample Cup on
4 - 3
