1 About the AccuPyc II
M O
ULTIGAS PTION
The Multigas Option allows connection of up to four gases to one analyzer. See
on page B - 1.
C O
ONFIGURATION
For best fit with a sample, the AccuPyc II is available in multiple configurations.
All sample chamber volumes are nominal unless otherwise specified.
3
1 cm sample chamber
l
3
10 cm sample chamber
l
3
100 cm sample chamber
l
3
350 cm sample chamber
l
3
2000 cm sample chamber
l
3
100 cm High Pressure sample chamber
l
Best fit means the sample nearly fills the sample chamber and, therefore, optimizes the precision of
the results.
G B
LOVE OX
Provides for analysis of samples in which a controlled environment is required.
Options
Configuration
This unit consists of two separate modules. The controller is placed outside the glove box, while the
analysis module is placed inside the glove box. Up to six analysis modules may be placed in the glove
box, all controlled by one external control module.
1 - 8
PTIONS
Description
3
1 cm sample chamber
l
3
10 cm sample chamber
l
3
100 cm sample chamber
l
3
350 cm sample chamber
l
3
2000 cm sample chamber
l
3
100 cm High Pressure sample chamber
l
Multigas Option
