Olli and Ozzi
Instruction Manual
This belt-positioning booster seat (booster seat)
is designed for use by children who meet
these requirements:
HEIGHT
101–145 cm
40–57 in.
• Read and understand all instructions in this manual and in your vehicle owner's
manual before installing or using this booster seat.
• The child's safety depends on you correctly installing and using this booster seat.
Failure to properly install or use this booster seat increases the risk of serious
injury or death to the child and others in a sharp turn, sudden stop or crash.
A01-0021-CA-A2
WEIGHT
MINIMUM AGE
18–54 kg
4+ years
40–120 lb
WARNING
March 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Olli and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Clek Olli

Summary of Contents for Clek Olli

  • Page 1 Olli and Ozzi Instruction Manual This belt-positioning booster seat (booster seat) is designed for use by children who meet these requirements: HEIGHT WEIGHT MINIMUM AGE 101–145 cm 18–54 kg 4+ years 40–57 in. 40–120 lb WARNING • Read and understand all instructions in this manual and in your vehicle owner’s manual before installing or using this booster seat.
  • Page 2 Checklist for Proper Use For proper use read and understand all instructions and booster seat labels.  Child weighs between 18 and 54 kg (40 and 120 lb), height is between 101 and 145 cm (40 and 57 in.)  Child is at least 4 years of age Child is sitting in the booster seat in a forward facing seating position in a rear seat ...

  • Page 3: Table Of Contents

    Limited Warranty ..................... 33 Warranty Limitations ..................34 Limitation of Warranties and State/Provincial Law Rights ........34 ® Clek and Clek logos, Olli, Ozzi, and Oobr are registered trademarks of Clek Inc. For a complete list of Clek Inc. trademarks please visit www.clekinc.com/trademarks.

  • Page 4: General Information

    • Engineered energy absorbing comfort-cube construction for added comfort • Optional seat covers available For concerns related to the parts, use or maintenance of this product, please contact us at: Clek Inc. Attn: Customer Service 226 Lesmill Road Toronto, Ontario Canada...

  • Page 5: Booster Seat Features

    • Do not use this booster seat after an accident of any kind. An accident can cause damage to the booster seat that you cannot see. 1 UAS Connectors 2 Belt-routing surface 3 Armrests 4 comfort-cube 5 Quick Release System 6 Removable & washable seat cover 7 drink-thingy 8 Manual Release System (olli model only)

  • Page 6: Registration And Recall Information

    Registration and Recall Information WARNING Child restraints could be recalled for safety reasons. You must register this restraint (booster seat) to be reached in a recall. Model Name: _____________________________________________________________________ Serial Number: ___________________________________________________________________ Date of Manufacture: _______________________________________________________________ (yyyy/mm/dd) Date of Purchase: _________________________________________________________________...

  • Page 7: Registering Your Booster Seat

    Child restraints could be recalled for safety reasons. You MUST register this restraint (booster seat) to be reached in a recall. Send your name, address and the restraint’s model number and manufacturing date to: Clek Inc. 226 Lesmill Road Toronto, Ontario, Canada, M3B 2T5 or call 1-866-656-2462 or register online at: www.clekinc.ca/register...

  • Page 8: Warnings

    Warnings WARNING Failure to properly use this booster seat or follow these warnings can result in serious injury or death of the child. Please read and follow all booster seat and vehicle instructions carefully. • Do not install or use this booster seat until you read and understand the instructions in this manual and in your vehicle owner’s manual.
  • Page 9 WARNING • WARNING! Use only the vehicle’s lap and shoulder belt system when restraining the child in this booster seat. You must properly route the seat belt underneath the armrests on this booster seat. Do not use this booster seat with motorized, door mounted, or lap-only belt systems.
  • Page 10 • Do not use accessories or parts with this booster seat other than those provided by Clek Inc. Use of accessories or parts from other manufacturers could alter the performance of the booster seat.

  • Page 11: Certification

    Certification • This booster seat conforms to all applicable requirements of Canadian Motor Vehicle Safety Standard 213.2 and is certified for use in motor vehicles • This booster seat is not certified for aircraft use because aircraft seats do not have shoulder belts Vehicle Classification This booster seat is for use only in the following classes of vehicle: passenger cars, trucks,...

  • Page 12: American Academy Of Pediatrics (Aap) Recommendations

    American Academy of Pediatrics (AAP) Recommendation The AAP advises parents to keep their children in a car seat with a harness for as long as possible, until they reach the maximum height and weight limit for their seat. Children who have exceeded the limits of their harnessed car seat should use a booster seat until the vehicle’s lap and shoulder seat belt fit properly.

  • Page 13: Vehicle Requirements

    Figure 2. The clek booster seat has been designed to attach securely to the vehicle’s UAS lower anchors.

  • Page 14: Vehicle Seat Location Requirements

    Vehicle Seat Location Requirements WARNING Improper placement of the booster seat in your vehicle increases the risk of serious injury or death. Some seating positions in your vehicle may not be safe for this booster seat. Some vehicles do not have any seating positions that can be used safely with the booster seat.
  • Page 15 • Install this booster seat only on vehicle seats that face forward. DO NOT install this booster seat on vehicle seats facing sideways or backwards, as shown in Figure 5. Figure 5 • Only use the booster seat on vehicle seats with seat backs that lock in an upright position.

  • Page 16: Vehicle Seat Belt Requirements

    Vehicle Seat Belt Requirements WARNING • Many seat belt systems are not safe to use with this booster seat. Pay careful attention to these systems; some of the seat belts that are not safe to use look very much like seat belts that are safe to use. If you are unsure, consult your vehicle owner’s manual or call 1-866-656-2462.
  • Page 17 WARNING • NEVER use a lap-only belt. Use with a lap-only belt could result in serious injury or death to the child, as shown in Figure 7a. • NEVER use a passive restraint – lap or shoulder belt mounted on door, as shown in Figure 7b.

  • Page 18: Installing/Removing Booster Seat In Vehicle

    Installing/Removing Booster Seat in Vehicle WARNING • The child’s safety depends on you correctly installing and using this booster seat. Failure to properly install or use this booster seat increases the risk of serious injury or death to the child and others in a sharp turn, sudden stop or crash. •...

  • Page 19: Installing Booster Seat In Vehicle Using Uas Connectors

    Installing Booster Seat in Vehicle using UAS Connectors Step 1 Select a forward facing vehicle position which has a lap and shoulder belt. Locate the UAS lower anchors (as explained in the “UAS Anchorage System” section of this manual or refer to your vehicle owner’s manual), as shown in Figures 8 and 9.
  • Page 20 Step 3 Press the UAS Connectors against the UAS lower anchors until you hear each UAS Connector click, as shown in Figures 12 and 13. Figure 12 Figure 13 If UAS Connectors fail to connect to the UAS lower anchors, you can still use this seat by securing the vehicle seat belt under neath the armrests.
  • Page 21 WARNING Do not secure this booster seat to the vehicle’s UAS anchorage system if the seat belt or seat belt buckle is not easily accessible with the booster seat latched in place or if either of the following conditions exist, as shown in Figures 15a and 15b. Figure 15a Figure 15b Seat belt buckle is...

  • Page 22: Installing Booster Seat In Vehicle Without Using Uas Connectors

    Installing Booster Seat in Vehicle without using UAS Connectors Step 1 Select a forward facing vehicle position which has a lap and shoulder belt. Position the booster seat firmly against seat back with UAS Connectors tucked into the crease between the seat back and seat cushion, as shown in Figures 16 and 17.

  • Page 23: Removing Booster Seat In Vehicle

    Figure 18. Repeat for the other UAS Connector. Figure 18 QUICK RELEASE (olli model only) Locate the release strap hanging at the front of the seat. Place one hand firmly on the front edge of the booster seat. Use the other hand...

  • Page 24: Securing Child In Booster Seat

    Securing Child in Booster Seat WARNING • Only use this booster seat with children who weigh between 18–54 kg (40 - 120 lb) and whose height is between 101–145 cm (40 - 57 in.). • To avoid injury, the child must be secured by an adult. NEVER allow the child to buckle themselves in this booster seat.
  • Page 25 Step 2 The child MUST sit in the booster seat with their back flat against the vehicle seat back. The tops of the child’s ears MUST be below the top of the vehicle seat back or a fully deployed head restraint on the vehicle seat, as shown in Figure 21.
  • Page 26 Step 4 Pull the shoulder belt across the child’s chest while positioning BOTH the lap and shoulder belt underneath the inboard armrest, as shown in Figure 23. Buckle the seat belt. Use only the vehicle’s lap and shoulder belt system when restraining the child in this booster seat. NEVER use a vehicle lap-only belt system.
  • Page 27 Step 5 When sitting on the booster seat, the shoulder belt MUST lie snug across the midpoint of the child’s chest and across the GREEN zone, as shown in Figure 24. Figure 24 Step 6 Vehicle seat belts MUST fit snug and lay flat against the child and MUST not be loose or twisted.
  • Page 28 Step 7 The lap belt MUST sit low and snug on the child’s hips. Pull on the shoulder belt to tighten. The shoulder belt MUST be centered over the child’s shoulder and lie across the mid point of the child’s chest. WARNING •...

  • Page 29: Owner's Manual Storage

    Owner’s Manual Storage After carefully reading and following these instructions, store the instruction manual in its pocket located on the bottom of the seat, as shown in Figure 27. Figure 27...

  • Page 30: Care & Cleaning

    Care & Cleaning WARNING Do not use accessories or parts other than those provided by Clek Inc. use of accessories or parts from other manufacturers could alter the performance of the booster seat. Removing Cover 1. Turn the seat so the bottom is facing up, as shown in Figure 28.
  • Page 31 2. Pull up on the bottom flap and sides of the seat cover releasing the fastening strips. Flip the bottom flap forward so that it hangs in front of the seat, as shown in Figure 29. 3. Unfasten the triangular flaps and flip them sideways so that they hang off to the side of the seat, as shown in Figure 29.
  • Page 32 Reinstalling Cover 1. Place the base frame right side up with the UAS Connectors pointing toward your body, as shown in Figure 30. toward body 2. Place the foam pad on the frame, such that the underside grooves are aligned with the grooves in the seat frame.
  • Page 33 5. Tuck the seat cover inside the armrests, as shown in Figure 32. Figure 32 6. Pull the cover over the back corners until it fits snug around the frame (Ensure that the foam pad has not shifted and that it sits properly on the frame), as shown in Figure 33.

  • Page 34: Service & Accessories

    7. Turn the booster seat over so the bottom is facing up, as shown in Figure 34. 8. Re-attach triangular flaps at the fastening strip, as shown in Figure 34. 9. Pull on the bottom flap and re-attach fastening strip, as shown in Figure 34. Figure 34 Service &...

  • Page 35: Warranty

    (1) year from the date of original purchase (the “Warranty Period”). During the Warranty Period, Clek Inc. will, at its option, repair or replace this product if it is found by the manufacturer to be defective in material or workmanship. Clek Inc. reserves the right to discontinue or change parts, fabrics, models, or products, or to substitute this product with a comparable model or product.

  • Page 36: Warranty Limitations

    In no event will Clek Inc. or the dealer selling this product be liable to you for any damages, including incidental or consequential damages, arising out of the use or inability to use this product.
