Olli and Ozzi
Instruction Manual
This belt-positioning booster seat (booster seat)
is designed for use by children who meet
these requirements:
Height
40–57 in.
101–145 cm.
• READ AND UNDERSTAND ALL INSTRUCTIONS IN THIS MANUAL AND IN YOUR
VEHICLE OWNER'S MANUAL BEFORE INSTALLING OR USING THIS BOOSTER SEAT.
• THE CHILD'S SAFETY DEPENDS ON YOU CORRECTLY INSTALLING AND USING THIS
BOOSTER SEAT. Failure to properly install or use this booster seat increases the risk
of serious injury or death to the child and others in a sharp turn, sudden stop or
crash.
APR2012
Weight
Recommended Age
40–120 lb.
4 years & up
18–54 kg.
WARNING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Olli and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Clek Olli

Summary of Contents for Clek Olli

  • Page 1 000011 Olli and Ozzi Instruction Manual This belt-positioning booster seat (booster seat) is designed for use by children who meet these requirements: Height Weight Recommended Age 40–57 in. 40–120 lb. 4 years & up 101–145 cm. 18–54 kg. WARNING • READ AND UNDERSTAND ALL INSTRUCTIONS IN THIS MANUAL AND IN YOUR VEHICLE OWNER’S MANUAL BEFORE INSTALLING OR USING THIS BOOSTER SEAT.
  • Page 2 checklist for proper use For proper use read and understand all instructions and booster seat labels. Child weighs between 40 and 120 pounds/18 and 54 kilograms, height is between 40 and 57 inches/101 and 145 centimeters Child is at least 4 years of age Child is sitting in the booster seat in a forward facing seating position in a rear seat of the vehicle The tops of the child’s ears are below the top of the vehicle seat back or the vehicle...

  • Page 3: Table Of Contents

    Limited Warranty ..................... 35 Warranty Limitations ..................36 Limitation of Warranties and State/Provincial Law Rights ........36 ® Clek and Clek logos, Olli, Ozzi, and Oobr are registered trademarks of Clek Inc. For a complete list of Clek Inc. trademarks please visit www.clekinc.com/trademarks.

  • Page 4: General Information

    3 Armrests • Optional seat covers available 4 comfort-cube ™ For concerns related to the parts, use or maintenance of this product, please contact us at: 5 Quick Release System Clek Inc. 6 Removable & 12 Upjohn Rd, Suite 1 washable seat cover Toronto, Ontario, Canada 7 drink-thingy ™*...

  • Page 5: Registration And Recall Information

    Registering Your Booster Seat Please fill in the information on page four for your records. The model name, serial number and manufacturing date can be found on a label affixed to the underside of the WARNING booster seat frame. CHILD RESTRAINTS COULD BE RECALLED FOR SAFETY REASONS. YOU MUST REGISTER THIS RESTRAINT (BOOSTER SEAT) TO BE REACHED IN A RECALL. Model Name: _____________________________________________________________________ Model Name: olli Clek Inc., Toronto, Ontario Canada Manufactured in: Serial No.: 81473500101 Serial Number: ___________________________________________________________________ Manufactured in: __________________________________________________________________ Fill out the prepaid registration postcard attached to the seat and mail it today. Child restraints could be recalled for safety reasons. You MUST register this restraint Date of Purchase: _________________________________________________________________ (booster seat) to be reached in a recall. Send your name, address and the restraint’s...

  • Page 6: Warnings

    warnings WARNING WARNING FAILURE TO PROPERLY USE THIS BOOSTER SEAT OR FOLLOW THESE WARNINGS CAN RESULT IN SERIOUS INJURY OR DEATH OF THE CHILD. PLEASE READ AND FOLLOW ALL BOOSTER SEAT AND VEHICLE INSTRUCTIONS CAREFULLY. FAILURE TO PROPERLY USE THIS BOOSTER SEAT OR FOLLOW THESE WARNINGS • DO NOT USE THIS BOOSTER SEAT IF THE TOPS OF THE CHILD’S EARS ARE CAN RESULT IN SERIOUS INJURY OR DEATH OF THE CHILD. PLEASE READ AND ABOVE THE TOP OF THE VEHICLE SEAT BACK OR A FULLY DEPLOYED HEAD FOLLOW ALL BOOSTER SEAT AND VEHICLE INSTRUCTIONS CAREFULLY. RESTRAINT ON THE VEHICLE SEAT. SEVERE HEAD OR NECK INJURIES COULD RESULT WITHOUT PROPER HEAD SUPPORT. • DO NOT INSTALL OR USE THIS BOOSTER SEAT UNTIL YOU READ AND UNDERSTAND THE INSTRUCTIONS IN THIS MANUAL AND IN YOUR VEHICLE • WARNING! USE ONLY THE VEHICLE’S LAP AND SHOULDER BELT SYSTEM WHEN OWNER’S MANUAL. DO NOT LET OTHERS INSTALL OR USE THIS BOOSTER RESTRAINING THE CHILD IN THIS BOOSTER SEAT. YOU MUST PROPERLY ROUTE SEAT UNLESS THEY UNDERSTAND HOW TO CORRECTLY INSTALL AND USE IT. THE SEAT BELT UNDERNEATH THE ARMRESTS ON THIS BOOSTER SEAT. DO NOT USE THIS BOOSTER SEAT WITH MOTORIZED, DOOR MOUNTED, OR LAP- • THE CHILD’S SAFETY DEPENDS ON YOU CORRECTLY INSTALLING AND USING ONLY BELT SYSTEMS. THIS BOOSTER SEAT. FAILURE TO PROPERLY INSTALL OR USE THIS BOOSTER SEAT INCREASES THE RISK OF SERIOUS INJURY OR DEATH TO THE CHILD AND • ACCORDING TO ACCIDENT STATISTICS, CHILDREN ARE SAFER WHEN OTHERS IN A SHARP TURN, SUDDEN STOP OR CRASH. PROPERLY RESTRAINED IN REAR VEHICLE SEATING POSITIONS, RATHER THAN FRONT SEATING POSITIONS. BEFORE USING THIS BOOSTER SEAT PLEASE • TO AVOID INJURY, THIS BOOSTER SEAT MUST BE INSTALLED BY AN ADULT. REFERENCE YOUR VEHICLE OWNER’S MANUAL FOR INFORMATION ABOUT NEVER ALLOW THE CHILD TO BUCKLE THEMSELVES IN THIS BOOSTER SEAT. AIR BAGS AND BOOSTER SEAT USE. NEVER USE THIS BOOSTER SEAT IN A • ONLY USE THIS BOOSTER SEAT WITH CHILDREN WHO WEIGH BETWEEN FRONT VEHICLE SEAT LOCATION UNLESS RECOMMENDED BY YOUR VEHICLE 40–120 POUNDS/18–54 KILOGRAMS AND WHOSE HEIGHT IS BETWEEN OWNER’S MANUAL.
  • Page 7 SYSTEM IF AVAILABLE. THIS BOOSTER SEAT MAY STILL BE USED IN VEHICLES OR MANUFACTURE. THE DATE OF MANUFACTURE CAN BE FOUND ON THE LABEL REAR SEAT POSITIONS WITHOUT A LATCH ANCHORAGE SYSTEM PROVIDED AFFIXED TO THE UNDERSIDE OF THE BOOSTER SEAT FRAME. THE BOOSTER SEAT IS PROPERLY POSITIONED ON THE VEHICLE SEAT AND THE • DO NOT ATTEMPT TO MAKE REPAIRS TO OR OTHERWISE MODIFY OR TAMPER CHILD AND THE BOOSTER SEAT ARE PROPERLY SECURED USING THE VEHICLE’S WITH THIS BOOSTER SEAT. FOR INSTRUCTIONS ON PROPER REMOVAL OF THE SEAT BELTS. SEAT COVER, SEE SECTION TITLED “CARE & CLEANING.” • DO NOT USE THIS BOOSTER SEAT IN A SEATING POSITION WHERE THE SEAT • NEVER USE THIS BOOSTER SEAT IF IT HAS DAMAGED OR MISSING PARTS. BELT BUCKLE IS NOT EASILY ACCESSIBLE WITH THE BOOSTER SEAT LATCHED DO NOT USE A CUT, DAMAGED, FRAYED OR INOPERABLE VEHICLE SEAT BELT. IN PLACE. • DO NOT USE ACCESSORIES OR PARTS WITH THIS BOOSTER SEAT OTHER THAN • NEVER LEAVE THIS BOOSTER SEAT UNSECURED IN YOUR VEHICLE. THIS THOSE PROVIDED BY CLEK INC. USE OF ACCESSORIES OR PARTS FROM OTHER BOOSTER SEAT MUST REMAIN CONNECTED TO THE LATCH LOWER ANCHORS MANUFACTURERS COULD ALTER THE PERFORMANCE OF THE BOOSTER SEAT. IN THE VEHICLE OR SECURED BY THE VEHICLE’S SEAT BELT EVEN WHEN NOT IN USE. IN A SHARP TURN, CRASH OR SUDDEN STOP, AN UNSECURED • THIS BOOSTER SEAT CAN BECOME VERY HOT IF LEFT IN THE SUN AND CAN BOOSTER SEAT CAN BE THROWN AROUND AND COULD SEVERELY INJURE BURN THE CHILD’S SKIN. ALWAYS TOUCH THE SURFACES OF THE PARTS FIRST VEHICLE OCCUPANTS. BEFORE PUTTING THE CHILD IN THE BOOSTER SEAT. • NEVER LEAVE THE CHILD UNATTENDED. NEVER TAKE THE CHILD OUT OF THE • KEEP THIS MANUAL IN THE STORAGE POUCH LOCATED ON THE BOTTOM OF BOOSTER SEAT OR TRY TO TEND TO THE CHILD’S NEEDS WHILE THE VEHICLE THE BOOSTER SEAT FOR FUTURE USE. IS MOVING. • NEVER USE A SECOND-HAND BOOSTER SEAT OR A BOOSTER SEAT WHOSE • NEVER ALLOW ANY CHILD TO PLAY WITH THIS BOOSTER SEAT.

  • Page 8: Certification

    certification height and weight limitations • This booster seat conforms to all applicable Federal Motor Vehicle Safety Standards and WARNING is certified for use in motor vehicles • This booster seat is not certified for aircraft use because aircraft seats do not have shoulder belts • DO NOT USE THIS BOOSTER SEAT IF THE CHILD DOES NOT MEET ALL OF THE CHILD SIZE REQUIREMENTS LISTED BELOW. Using this booster seat with a child vehicle classification who does not meet these requirements will increase the risk of serious injury or death to the child. This booster seat is for use only in the following classes of vehicle: Passenger Cars, Trucks, and Multi-Purpose Passenger Vehicles such as SUVs (sports utility vehicles) and CUVs The child MUST meet ALL of the following 40–120 lb./ 18–54 kg.

  • Page 9: Vehicle Requirements

    If you are not sure where to Anchorage System (UAS). The term refers to the place the booster seat in your vehicle, consult your vehicle owner’s manual or call pair of fixed lower anchors built into the crease 1-866-656-2462. between the seat back and seat cushion. The clek ™ booster seat has been designed to attach securely to the vehicle’s LATCH lower anchors. • According to accident statistics, children are safer when properly restrained in rear • 2003 model year vehicles or newer have LATCH...

  • Page 10: Vehicle Seat Belt Requirements

    • Install this booster seat only on vehicle seats that face forward. DO NOT install this Vehicle Seat Belt Requirements booster seat on vehicle seats facing sideways or backwards. WARNING • MANY SEAT BELT SYSTEMS ARE NOT SAFE TO USE WITH THIS BOOSTER SEAT. Pay careful attention to these systems; some of the seat belts that are NOT safe to use look very much like seat belts that are safe to use. If you are unsure, consult your vehicle owner’s manual or call 1-866-656-2462. • NEVER USE THIS BOOSTER SEAT IF IT HAS DAMAGED OR MISSING PARTS. • Only use the booster seat on vehicle seats with seat backs that lock in an upright DO NOT USE A CUT, DAMAGED, FRAYED OR INOPERABLE VEHICLE SEAT BELT. position.

  • Page 11: Installing/Removing Booster Seat In Vehicle

    installing/removing booster seat WARNING in vehicle • NEVER USE A LAP-ONLY BELT. USE WITH A LAP-ONLY BELT COULD RESULT IN SERIOUS INJURY OR DEATH TO THE CHILD (SEE FIGURE 1). • NEVER USE A PASSIVE RESTRAINT – LAP OR SHOULDER BELT MOUNTED ON WARNING DOOR (SEE FIGURE 2). • NEVER USE A PASSIVE RESTRAINT – LAP BELT WITH MOTORIZED • THE CHILD’S SAFETY DEPENDS ON YOU CORRECTLY INSTALLING AND USING THIS SHOULDER BELT (SEE FIGURE 3). BOOSTER SEAT. Failure to properly install or use this booster seat increases the risk of • NEVER USE VEHICLE BELTS THAT ARE ATTACHED TO THE DOOR IN ANY WAY serious injury or death to the child and others in a sharp turn, sudden stop or crash. OR THAT MOVE ALONG A TRACK TO AUTOMATICALLY SURROUND THE • THIS BOOSTER SEAT IS DESIGNED TO BE USED WITH THE VEHICLE’S LATCH PASSENGER WHEN THE DOOR IS CLOSED (SEE FIGURE 2 AND FIGURE 3). ANCHORAGE SYSTEM. ALWAYS SECURE THIS BOOSTER SEAT TO THE VEHICLE’S LATCH ANCHORAGE SYSTEM IF AVAILABLE. THIS BOOSTER SEAT MAY STILL BE USED IN VEHICLES OR REAR SEAT POSITIONS WITHOUT A LATCH ANCHORAGE UNSAFE VEHICLE SEAT BELT SYSTEMS...

  • Page 12: Installing Booster Seat In Vehicle Using Latch Connectors

    Installing Booster Seat in Vehicle Step 3. Press the LATCH connectors using LATCH connectors against the LATCH lower anchors until you hear each LATCH connector click. Step 1. Select a forward facing vehicle position which has a lap and shoulder belt. Locate the LATCH lower anchors (as explained in the “LATCH Anchorage System”...

  • Page 13: Installing Booster Seat In Vehicle Without Using Latch Connectors

    Installing Booster Seat in Vehicle WARNING without using LATCH connectors DO NOT SECURE THIS BOOSTER SEAT TO THE VEHICLE’S LATCH ANCHORAGE Step 1. SYSTEM IF THE SEAT BELT OR SEAT BELT BUCKLE IS NOT EASILY ACCESSIBLE WITH Select a forward facing THE BOOSTER SEAT LATCHED IN PLACE OR IF EITHER OF THE FOLLOWING vehicle position which has CONDITIONS EXIST (SEE FIGURE 1 AND FIGURE 2). a lap and shoulder belt. Position the booster seat firmly against seat back with LATCH connectors tucked into the crease between the seat back and seat cushion.

  • Page 14: Removing Booster Seat In Vehicle

    Removing Booster Seat in Vehicle QUICK RELEASE (olli model only) ™ MANUAL RELEASE Locate the release strap hanging at the front of the seat. Locate the red buttons on the front of the LATCH connectors. Place one hand FIRMLY on the front edge of the booster seat.

  • Page 15: Securing Child In Booster Seat

    securing child in booster seat Step 2. The child MUST sit in the booster seat with their back flat against the vehicle seat back. The tops of the child’s ears MUST be below the top of the vehicle seat back or a fully deployed head restraint WARNING on the vehicle seat. Severe head or neck injuries could result without proper head support. • ONLY USE THIS BOOSTER SEAT WITH CHILDREN WHO WEIGH BETWEEN 40–120 POUNDS/18–54 KILOGRAMS AND WHOSE HEIGHT IS BETWEEN 40–57 INCHES/101–145 CENTIMETERS.
  • Page 16 Step 4. Step 5. Pull the shoulder belt across the child’s chest while positioning BOTH the lap and shoulder When sitting on the booster seat, the shoulder belt belt underneath the inboard armrest as shown. Buckle the seat belt. Use only the vehicle’s MUST lie snug across the mid point of the child’s lap and shoulder belt system when restraining the child in this booster seat. NEVER use a chest and across the GREEN zone as shown. vehicle lap-only belt system. Inboard Armrest Step 6. Vehicle seat belts MUST fit snug and lay flat against the child and MUST not be loose or twisted. A snug seat belt does not allow any slack. It lies in a relatively straight line without sagging. DO NOT position any part of the vehicle seat belt over the top of the armrest or behind the armrest.

  • Page 17: Owner's Manual Storage

    owner’s manual storage Step 7. The lap belt MUST sit low and snug on the child’s hips. Pull on the shoulder belt to tighten. The shoulder belt MUST be centered over the child’s shoulder and lie across the mid point of the child’s chest. After carefully reading and following these instructions, store the instruction manual in its pocket located on the bottom of the seat as shown. WARNING • DO NOT USE WITH THE SHOULDER BELT TOUCHING THE CHILD’S NECK OR FACE. • DO NOT USE WITH SHOULDER BELT POSITIONED UNDER CHILD’S ARM OR BEHIND THE CHILD (SEE FIGURE 1 AND FIGURE 2). • DO NOT ALLOW CHILD TO SLIDE DOWN IN BOOSTER SEAT, WHICH COULD POSITION THE VEHICLE’S LAP BELT ACROSS THE CHILD’S ABDOMEN AND THE SHOULDER BELT OVER THE CHILD’S NECK OR FACE (SEE FIGURE 3). Figure 1 Figure 2 Figure 3...

  • Page 18: Care & Cleaning

    DO NOT USE ACCESSORIES OR PARTS OTHER THAN THOSE PROVIDED BY 4. Starting from the back, push down on CLEK INC USE OF ACCESSORIES OR PARTS FROM OTHER MANUFACTURERS the sides of the seat cushion cover, COULD ALTER THE PERFORMANCE OF THE BOOSTER SEAT. loosening the cover from the seat frame. Removing Cover 1.
  • Page 19 Reinstalling Cover 3. Unfasten the seat cover and align it with the seat frame. 1. Place the base frame right side up with 4. Pull the cover over the frame, starting the LATCH connectors pointing toward from the front of the seat (opposite your body.

  • Page 20: Service & Accessories

    Limited Warranty fastening strip. 9. Pull on the bottom flap and re-attach Clek Inc. warrants to the original consumer purchaser that this product will be free from fastening strip. defects in material and workmanship for one (1) years from the date of original purchase (the “Warranty Period”). During the Warranty Period, Clek Inc. will, at its option, repair or replace this product if it is found by the man ufacturer to be defective in material or workmanship.

  • Page 21: Warranty Limitations

    Some states/provinces do not allow limitations as to how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations may not apply to you. This warranty gives you specific legal rights, and you may have other rights, which vary from state/province to state/province. Neither Clek Inc. nor the dealer selling this product has author i zed any person to create for it any other warranty, obligation, or liability in connection with this product.
  • Page 22 Clek Inc. 12 Upjohn Rd., Suite 1 Toronto, Ontario, Canada M3B 2V9 1-866-656-2462 rel.01APR12...
