Summary of Contents for Clek Q-Tether
- Page 1 Foonf + Fllo Q-Tether Manual...
- Page 2 Plate is located on top of vehicle seat back. NEVER use Q-tether with Splitter Plate in front of vehicle seat back. • Do not tighten Q-tether more than needed to remove slack. Overtightening Q-tether could shift the position of the car seat resulting in a seat too upright.
- Page 3 Tether Connector Strap is tightened so that Splitter Plate is located on top of vehicle seat back. Loops at end of Q-Tether are properly attached to Splitter Plate and completely inside the slot. Q-Tether adjuster is located on side of vehicle where child will be loaded and unloaded.
-
Page 4: Vehicle Information
Vehicle Information • Tether anchors have been provided in second row seating positions by most vehicle manufacturers since 2001. • Top tether anchors are found behind the vehicle seat as shown in Figure 1. • If covered, the tether anchor Figure 1 locations may be identified by a symbol as shown in Figure 2. - Page 5 Q-Tether Features 1 Tether Hook Tether Connector Adjuster Tether Connector Strap 4 Splitter Plate 5 Q-Tether Attachment Loops 6 Q-Tether Adjuster 7 Q-Tether Strap...
- Page 6 IMPORTANT: Car seat MUST be properly installed according to the instructions in the car seat manual in a vehicle seating position with a designated tether anchor before installing Q-Tether. Installing Q-Tether Step 1 Locate tether anchor as shown in Figure 3. If covered, the tether...
- Page 7 Check that Q-Tether Adjuster is connected to side of Splitter Plate closest to where child will be loaded and unloaded. Option 1: If Q-Tether Adjuster needs to be moved to other side of Splitter Plate: • Remove loop at each...
- Page 8 Q-Tether Strap by sliding looped end into slot in Splitter Plate as shown in Figure 8. Figure 8 Option 2: If Q-Tether Adjuster is on correct side of Splitter Plate: • Remove one loop at end of Q-Tether Strap...
- Page 9 Harness and seat, as shown in Figure 12. Step 8 Figure 12 IMPORTANT: Check that Q-Tether Strap is flat and not twisted before attaching loop to Splitter Plate. Attach loop at end of Q-Tether Strap to Splitter Plate by sliding Strap into slot in Splitter Plate as shown in Figure 13.
- Page 10 Step 9 Pull free end of Q-Tether Connector Strap until Splitter Plate is positioned on top of vehicle seat back as shown in Figure 14. IMPORTANT: To prevent Figure 14 injury to the child in a sudden stop or crash...
- Page 11 Step 10 Position Q-Tether Strap so that it passes through both Forward-Facing Belt Lock- offs and pull on free end of Q-Tether Strap to tighten as Figure 16 shown in Figure 16 and 17. IMPORTANT: NEVER tighten Q-Tether Strap further than needed to remove slack.
-
Page 12: Final Check
Q-Tether Strap is positioned in both Forward-Facing Lock-offs and both Forward-Facing Lock-offs are closed. Q-Tether Adjuster is located on side of seat closest to where child will be loaded and unloaded. Loading/Unloading Child For ease of loading and unloading, it is recommended that Q-Tether... - Page 13 Q-Tether Strap until Strap reaches full length as shown in Figure 19. Figure 19 Tightening Q-Tether Pull free end of Q-Tether Strap until slack is removed as shown in Figure 20. IMPORTANT: NEVER tighten Q-Tether Strap further than Figure 20 needed to remove slack.
-
Page 14: Troubleshooting
Troubleshooting For instructions on troubleshooting your Clek product, please visit: www.clekinc.com/support/q-tether Accessories Optional Clek accessories may be purchased at: www.clekinc.com/accessories... -
Page 15: Warranty
(1) years from the date of original purchase (the “Warranty Period”). During the Warranty Period, Clek Inc. will, at its option, repair or replace this product if it is found by the manufacturer to be defective in material or workmanship. Clek Inc.
