5.3.3

Installation with adhesive strips

Depending on the ground, installation can be performed using the supplied dou-
ble-sided adhesive tapes. Installation is possible on different grounds, as e. g. ma-
sonry, furniture, tiles or glass.
Select an appropriate installation position.
If the installation is done with adhesive strips, the installation surface must
be smooth, level, undamaged, clean, and free from grease and solvents.
1. Remove the protective foil from one side of the adhesive strip.
2. Fix the adhesive strip on the back side of the installation bottom in the recesses
provided for this (see page 4 fig. 2c).
3. Remove the protective foil from the other side of the adhesive strip.
4. Align the device horizontally to the desired position and press it on.

6 Operating modes and configuration

The setting wheel E (see page 4 fig. 1) provides the operating functions of the de-
vice. Depending on the configuration, the settings are transmitted to the Altech V3
IP Base station or to the IP app.
6.1

Configuration menu

The configuration menu is opened by pressing and holding the setting wheel (E).
The following symbols/menus are available by rotating the setting wheel; shortly
pressing the wheel will select them.
