3. Hold the installation bottom to the installation position. Take care to align the
installation bottom correctly (see page 4 fig. 2a/b).
4. Align the installation bottom horizontally.
5. Mark two diagonally opposite bore holes using the installation bottom (see
page 5 fig. 2a).
If wood walls are present, the screws can be screwed directly into the
wood. Pre-drilling with a 1.5 mm wood drill can facilitate the installation of
DK
the screws.
NO
6. For stone walls, drill the holes at the marked positions with a 5 mm masonry
SE
drill.
7. Insert dowels into the bores.
FI
8. Install the installation bottom using the supplied screws (see page 4 fig. 5).
9. Position the device onto the installation bottom and latch it in (see page 5 fig.
FR
3).
GB GB
5.3.2

Installation in flush-type box

The fixing holes on the installation bottom can be used for installation on a flush-
type box (see page 4 fig. 2b).
1. If necessary, release the device from the installation bottom with a suitable
screwdriver (see page 5 fig. 4).
2. Align the installation bottom horizontally on the flush-type box.
3. Install the installation bottom with suitable screws (see page 4 fig. 2b).
4. Position the room control unit Display onto the installation bottom and latch it
into the clips (see page 5 fig. 3).
