Touchscreen Status Dial - Vertiv Liebert iCOM Installer/User Manual

Table 1.1 Main Display Controls and Options (continued)
Item Description
Lock/Unlock icon. Indicates whether or not the user and service options are accessible.
•
10
•
See Powering On the iCOM and Logging In/Unlocking Controls
11 Secondary content panel. When accessing settings/configuration via the menus, the settings display in the right, secondary panel.
Summary of current unit function. You can customize to show fan speed, cooling, percentages from any installed device, and any physical
12
(sensor) values.
13 Status Dial. Circular display of setpoints and environmental conditions of the unit. See
Teamwork mode icon. In a panel with "Status" content, the Teamwork Mode icon indicates the mode selected. For details and descriptions of the
14
teamwork controls, see
15 Control header. Controls to access the user and service menus. See
16 Status Header. Displays the alarm status, unit identification, and the current date and time.

1.2 Touchscreen Status Dial

The dial in the primary control panel displays read-only control sensors, setpoints, and environmental conditions for unit
status at a glance. See Figure 1.2 on the next page.
The center of the dial displays sensor readings and changes color according to alarm thresholds as the readings rise and
fall, see Dial Background Color Status Indication
Touching the center of the dial cycles through a set of sensor settings, and you can select the readings displayed, see
Adding and Adjusting Content
1 Getting Started with iCOM™
Locked icon: display is read-only
Unlocked icon: user or service is logged-in and options are accessible.
Teamwork Modes on page 63.
on page 5.
on page 93.
on page 6.
Touchscreen Status Dial
Control Header on page 6.
below.
3
