Table B.4 Service Menu Alarm Settings by Line ID (continued)
Line Parameter
ID Name
Event Delay Time (sec)
S2E2 Event Enabled
Event: COMP 2A SHORT CYCLE
Event Delay Time (sec)
S2E5 Event Enabled
Event: COMP 2B SHORT CYCLE
Event Delay Time (sec)
Event Enabled
S2E6
Event: GCD AMBIENT TEMP
DIFF
‒
S2E7 Event Enabled
Event: C1 FREEZE PROTECTION
‒
S2E8 Event Enabled
Event: C2 FREEZE PROTECTION
Event Delay Time (sec)
S2E9 Event Enabled
Event: DAMPER FAILURE
‒
SF2F Event Enabled
Event: BMS DISCONNECTED
Phase Loss MB01 shuts unit
down
Event Delay Time (sec)
S2F9
Event Enabled
Event: POWER 1 PHASE LOSS
Phase Loss MB02 shuts unit
down
Event Delay Time (sec)
S2G1
Event Enabled
Event: POWER 2 PHASE LOSS
156
Range
10 - 9999 sec
Disabled Enabled
MESSAGE WARNING ALARM
10 - 9999 sec
Disabled Enabled
MESSAGE WARNING ALARM
10 - 9999 sec
Disabled Enabled
MESSAGE WARNING ALARM
‒
Disabled Enabled
MESSAGE WARNING ALARM
‒
Disabled Enabled
MESSAGE WARNING ALARM
10 - 9999 sec
Disabled Enabled
MESSAGE WARNING ALARM
‒
Disabled Enabled
MESSAGE WARNING ALARM
0 - No
1 - Yes
10 - 9999 sec
Disabled Enabled
MESSAGE WARNING ALARM
0 - No
1 - Yes
10 - 9999 sec
Disabled Enabled
MESSAGE WARNING ALARM
Default
Description
Setting
10 sec
Enabled Compressor 2A short cycle.
WARNING
10 sec
Enabled Compressor 2B short cycle.
WARNING
60 sec
Enabled GCB ambient temperature
differential.
WARNING
‒
Enabled C1 freeze protection.
ALARM
‒
Enabled C2 freeze protection.
ALARM
10 sec
Enabled Damper failure.
ALARM
‒
Enabled BMS disconnected.
WARNING
1 (Yes)
10 sec
Power 1 phase loss.
Enabled
ALARM
1 (Yes)
10 sec
Power 2 phase loss.
Enabled
ALARM
