2. Mounting
Drill a hole in a mounting substrate as indicated in below figure.
Mounting recess width and depth requirements
Mount the display:
Use option A if the mounting substrate is accessible from both sides
Use option B if the mounting substrate is accessible from the front.
1
2
Mounting option A
Page 3
Mounting
