Specifications - Victron energy MPPT Control display Manual

7. Specifications

Supply voltage range when powered from battery
Supply voltage range when powered via VE.Direct cable
Power consumption with back-light turned off
Operating temperature range
Power cable fuse rating
Installation type
Front diameter
Front bezel
Body diameter
Body depth
Power cable length
Weight
Suitable for the entire Victron Energy BlueSolar MPPT and the SmartSolar MPPT solar charger range, with the exception of
the (since long) discontinued BlueSolar MPPT 70/15.
Page 14
MPPT Control display manual
Electrical
6.5 - 95Vdc
5Vdc
< 0.05W
-20 - +50°C (0 - 120°C)
100mA
Mechanical
Flush mount
63mm (2.5")
69 x 69mm (2.7x2.7")
52mm (2.0")
31mm (1.2")
1.5m
50g
Suitability
Specifications
