MPPT Control
Rev 0.1
Installation
Connect the MPPT Control to a BlueSolar MPPT with VE.Direct port using a VE.Direct cable.
If the MPPT Control is connected to a MPPT that shuts down at night, the MPPT Control can be connected to a battery using the
supplied cable. This way, the MPPT Control stays powered while the MPPT is off and the last received status, history and settings of
the MPPT can be viewed.
Specifications
Supply voltage range
Current draw, back light off
Operating temperature range
Models
Software version
Installation
Front
Front bezel
Body diameter
Body depth
Cables (included)
Buttons and display
Victron Energy B.V. | De Paal 35 | 1351 JG Almere | The Netherlands
General phone: +31 (0)36 535 97 00 | Fax: +31 (0)36 535 97 40
E-mail: sales@victronenergy.com | www.victronenergy.com
MPPT Control
6,5 - 95 VDC (Battery powered)
Supported MPPTs
All models with VE.Direct port, except the
INSTALLATION & DIMENSIONS
ACCESSORIES
cable with fuse for battery powered
SETUP
SELECT
On
There was a connection with the MPPT but the connection is lost.
Blinking
Off
A
B
C
D
E
F
S
T
U
V
W
X
5V (VE.direct powered)
< 4 mA
-20 - +50°C (0 - 120°F)
BlueSolar MPPT 70/15
All software versions >= 1.12
Flush mount
63 mm diameter
69 x 69 mm (2.7 x 2.7 inch)
52mm (2.0 inch)
31mm (1.2 inch)
operation
Cancel / back
Select / confirm
Change item or value
There is a connection with the MPPT.
The last know values will be shown.
There has not been a connection with a MPPT.
G
H
I
J
K
L
Y
Z
0
1
2
3
www.victronenergy.com
M
N
O
P
Q
R
4
5
6
7
8
9
Advertisement
Related Manuals for Victron energy MPPT Control
Summary of Contents for Victron energy MPPT Control
- Page 1 Connect the MPPT Control to a BlueSolar MPPT with VE.Direct port using a VE.Direct cable. If the MPPT Control is connected to a MPPT that shuts down at night, the MPPT Control can be connected to a battery using the supplied cable.
