Victron energy MPPT Control display Manual page 13

Some settings might be missing from the settings menu. The MPPT Control display only allows to change the most common
settings. More advance settings, like TX and RX port settings, are not accessible via the MPPT Control display. To configure
these settings use the VictronConnect App
Number Name
01 LOCK SETUP
02 BATTERY VOLTAGE
03 BATTERY TYPE
04 MAXIMUM CURRENT
05 BULK TIME LIMIT
06 ABSORPTION TIME LIMIT
07 ABSORPTION VOLTAGE
08 FLOAT VOLTAGE
09 TEMP COMPENSATION
10 LOAD OUTPUT
11 LOAD SWITCH HIGH
12 LOAD SWITCH LOW
13 CLEAR HISTORY
14 FACTORY DEFAULTS
15 BACKLIGHT INTENSITY
16 BACKLIGHT ALWAYS ON
17 SCROLL SPEED
18 SELECT TO EDIT
19 AUTO LOCK
20 SOFTWARE VERSION
21 SERIAL NUMBER
22 MPPT SOFTWARE
VERSION
23 MPPT SOFTWARE
VERSION
24 EQUALISATION VOLTAGE
25 EQUALIZE
Page 11
MPPT Control display manual
or, for solar chargers 60A and up, use a
When set to ON, none of the other settings can be changed. If an attempt is
made to change a setting the word "LOCK" is shown together with the setting
value.
Set to OFF to unlock, so other settings can be changed.
The system battery voltage; choose between a voltage setting or AUTO.
When set to automatic (AUTO), an A will be shown in front of the voltage
setting.
The charge algorithm for a specific battery type; set to FIXED or USER.
When set to FIXED, the rotary switch on the solar charger determines the
battery type.
When set to USER, all charging related settings can be edited.
As soon as any of the charging related settings are changed, this setting will
automatically set to USER.
The maximum charging current.
The maximum time the bulk charge stage is allowed to last.
The maximum time the absorption charge stage is allowed to last.
The battery voltage at which the solar charger switches from bulk to absorption
stage.
The battery voltage at which the solar charger switches from absorption to
float stage.
The temperature compensation coefficient in mV/°C for the whole battery bank
(not per individual battery).
The Load output operating mode. Possible values: OFF, AUTO (= BatteryLife),
ALT1, ALT2, ON, USER1, USER2
The high voltage level in case LOAD OUTPUT is set to USER1 or USER2
The low voltage level in case LOAD OUTPUT is set to USER1 or USER2
Clears the solar charger history
Resets the solar charger settings back to factory defaults.
Sets the back-light intensity of the MPPT Control LCD display.
Determines whether the back-light of the MPPT Control LCD display is always
on.
Determines the scroll speed of the MPPT Control.
When set to OFF, the MPPT Control first shows the value of a setting and
SELECT has to be pressed to be able to edit the value.
When set to ON, the LOCK SETUP setting will be automatically set to ON 2
minutes after a setting has been changed.
The software (firmware) version of the MPPT Control.
The serial number of the MPPT Control.
The software (firmware) version of the solar charger.
The serial number of the solar charger.
Equalization voltage.
Initiates a manual equalization.
SmartSolar Control display.
Setting
Operation
