SR – 068 Rev 1
DATE:
October 7, 2020
TO:
All Service and Parts Managers
SUBJECT: Crank Case Heater Kit for Inverter Split Systems
For reliability and longevity, inverter condensing units are designed to maintain compressor oil
at optimum conditions while the unit is in stand-by mode. This feature allows a small current
draw through the compressor windings to maintain proper oil temperature to provide
compressor protection in preparation for the next run cycle.
In some cases, homeowners may hear a high-pitched sound coming from the outdoor unit. This
is the result of current draw through the compressor windings and is not a defect with the
inverter unit. If you have a homeowner experiencing this condition and finds it objectionable, we
have developed a kit to install an external crankcase heater to maintain proper oil temperature
instead of utilizing the compressor windings on the inverter units.
This kit is not under the manufacturer's warranty and must be purchased by contacting your
service parts CSR. The part number for the kit is INVCCHK01.
Note: Please review IO-7005 (attached) before proceeding with the installation. The "New"
INVCCHK01 requires the use of the BTSDL01 (Bluetooth Shared Data Loader) in addition to
this kit to install the required shared data.
AVZC180241
AVZC200241
AVZC180361
AVZC200361
AVZC180481
AVZC200481
AVZC180601
AVZC200601
If you have questions regarding this bulletin, please contact
Produced by Goodman Business Unit Technical Services | 19001 Kermier Road | Waller, TX 77484
All rights reserved. Goodman products are subject to continuous improvements. Goodman reserves the right to modify
information in the bulletin without notice and without incurring any obligations. Amana
Corporation or its related companies and is used under license. All rights reserved.
Applicable Models
AVXC2000241
AVXC2000361
AVXC2000481
AVXC2000601
T: 888-593-9988 | F: 713-316-5541
GVZC200241
GVXC200241
GVZC200361
GVXC200361
GVZC200481
GVXC200481
GVZC200601
GVXC200601
TechServices@goodmanmfg.com
®
is a registered trademark of Maytag
1 of 1
