RX23W Group
16
32
32
RENESAS 32-Bit MCU
RX Family / RX200 Series
All information contained in these materials, including products and product specifications, represents
information on the product at the time of publication and is subject to change by Renesas Electronics
Corporation without notice. Please review the latest information published by Renesas Electronics
Corporation through various means, including the Renesas Electronics Corporation website
(http://www.renesas.com).
Target Board for RX23W User's Manual
Rev. 0.60 Nov
.
2019
Advertisement
Table of Contents
Related Manuals for Renesas RX Series
Summary of Contents for Renesas RX Series
- Page 1 All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Electronics Corporation without notice. Please review the latest information published by Renesas Electronics Corporation through various means, including the Renesas Electronics Corporation website (http://www.renesas.com).
- Page 2 You may not use any Renesas Electronics product for any application for which it is not intended. Renesas Electronics shall not be in any way liable for any damages or losses incurred by you or third parties arising from the use of any Renesas Electronics product for which the product is not intended by Renesas Electronics.
- Page 3 Precautions The following precautions should be observed when operating Target Board for RX23W product: The Target Board for RX23W is only intended for use in a laboratory environment under ambient temperature and humidity conditions. A safe separation distance should be used between this product and any sensitive equipment. Its use outside the laboratory, classroom, and study area or in area not conform to the protection requirements of the Electromagnetic Compatibility Directive could lead to prosecution.
- Page 4 The revision history only shows the summary of revised or added parts, and does not include all revisions. Refer to the text in this manual for details. The following documents apply to the RX23W Group. Make sure to use the latest versions for reference, available on the Renesas Electronics Web site. Document Type Description Document Title Document No.
- Page 5 Digilent Pmod™ Compatible connector. Pmod™ is registered to Digilent Inc. Pmod™ Digilent-Pmod_Interface_Specification Random Access Memory Renesas Flash Programmer Read Only Memory Serial Peripheral Interface Universal Serial Bus Bluetooth Low Energy All trademarks and registered trademarks are the property of their respective owners.
-
Page 6: Table Of Contents
Table of Contents Overview ......................... 7 Contents ..............................7 Purpose ..............................7 Features ..............................7 Preparation ..............................7 Board Specification Table .......................... 8 Block Diagram ............................9 2. Board Layout ........................10 3. Parts Layout ........................11 4. Operating Environment ....................12 5. -
Page 7: Overview
Rev.0.60 Nov. 26, 2019 1. Overview Contents Thank you for purchasing the Renesas evaluation tool "Target Board for RX23W". This product consists of the following item. Target Board for RX23W Purpose The Target Board for RX23W is an evaluation tool for Renesas microcontrollers. This manual describes the technical details of the Target Board for RX23W hardware. -
Page 8: Board Specification Table
Target Board for RX23W Overview Board Specification Table Table 1-1 shows the Target Board for RX23W specifications. Table 1-1: Board Specification Table Item Specification Part No: R5F523W8ADNG Evaluation MCU Package: 56-Pin QFN On-chip memory: ROM 512KB+8KB, RAM 64KB Size: 54.0mm x 90.0mm Board Size Thickness: 1.6mm USB connector: 5V Input... -
Page 9: Block Diagram
Target Board for RX23W Overview Block Diagram Figure 1-1 shows the block diagram of the Target Board for RX23W. Arduino™ Pmod™ Cut Pattern Header x2 Connector Connector Connector Power Supply Emulator Selection Evaluation MCU Antenna Circuit Header External Power Supply Header Reset Switch Power Main Clock... -
Page 10: Board Layout
Target Board for RX23W 2. Board Layout 2. Board Layout Figure 2-1 shows the external appearance of the top side of Target Board for RX23W. Current Emulator Consumption Reset Switch Measurement Header Current Consumptio Arduino Measuremen Headers t Header MCU Header ACT LED Power Evaluation... -
Page 11: Parts Layout
Target Board for RX23W 3. Parts Layout 3. Parts Layout Figure 3-1 shows the parts layout of Target Board for RX23W. 90.0mm Figure 3-1: Parts Layout R01UHxxxEG0100 Rev.0.60 Page 11 of 28 26, 2019... -
Page 12: Operating Environment
Figure 4-1 shows the operating environment of the Target Board for RX23W. Install the integrated development environment (IDE) from the following URL on the host PC. All the other required drivers are will be automatically installed with the IDE. https://www.renesas.com/rxtb USB Cable Target Board for RX23W... -
Page 13: User Circuit
Target Board for RX23W 5. User Circuit 5. User Circuit Evaluation MCU The MCU specification for the power supply, system clock, and reset at the time of shipment are as follows; Power supply: 3.3 V fixed (including analog power supply) System clock: Operated with on-chip oscillator Reset: Reset switch, IDE reset instruction Bluetooth Low Energy... -
Page 14: Emulator
Table 5-1.The connector shape is USB micro -B for Integrated Development Environment (IDE) and for Renesas Flash Programmer (RFP). Connect to the computer via the USB cable. If the power supply on the host side is ON, the Target Board for RX23W will be automatically power-supplied with the cable connection. -
Page 15: Usb Serial Port
Target Board for RX23W 5. User Circuit USB Serial Port The USB connector CN5 is connected to the FTDI USB serial conversion module and can be used as a virtual COM port. The USB serial connection relationship is shown below. Table 5-2 : Serial Port Connections Signal Name Function... -
Page 16: Act Led
Target Board for RX23W 5. User Circuit ACT LED The ACT LED displays the operation status of the emulator control software. The lighting conditions are shown below. The lighting color is green. Light On: Indicates that the emulator is connected to the target. Flickering: Indicates that the host machine (PC) has recognized the emulator. -
Page 17: External Power Supply Header
Target Board for RX23W 5. User Circuit External Power Supply Header When operating the evaluation MCU at an arbitrary voltage, or requiring current more than the USB current capacity, use the external power supply header (J6) for power supply. The available voltage depends on the evaluation MCU. -
Page 18: Pmod™ Connector
Target Board for RX23W 5. User Circuit Pmod™ Connector The Pmod ™ connector (PMOD1) has a through hole at a pitch of 2.54 mm and is connected to the evaluation MCU according to Pmod™ Interface Type 2 A. Note that the Pmod ™ connector has the pin assignment different from other headers. -
Page 19: Arduino™ヘッダ
Target Board for RX23W 5. User Circuit Arduino™ヘッダ The Arduino ™ header (J2,J3,J4,J5) has a through hole at a pitch of 2.54 mm and is connected to the evaluation MCU according to Arduino™ UNO R3. Table 5-4 shows the signal assign of the Arduino ™ header. The channel for interrupts is assigned to IRQ4 respectively. -
Page 20: Crrent Consumption Measurement Header
Target Board for RX23W 5. User Circuit Crrent Consumption Measurement Header The current consumption measurement header (J7) is used for measuring current consumption of the evaluation MCU. The current consumption can be measured by connecting an ammeter to the evaluation MCU. Note that the cut pattern (SS20) should be cut when using this header. -
Page 21: Configuration
Target Board for RX231 6. Configuration Configuration Modifying the Target Board for RX23W This section describes how to change the Target Board for RX23W setting by using option link resistance. An option link resistor is a 0Ω surface mount resistor, which is used to short or isolate a part of circuits. See the 6.2 below for the list of option links by function. -
Page 22: Handling Precautions
Target Board for RX23W Handling Precautions Handling Precautions Board Thickness Please be extra careful when handling the Target Board for RX23W as the board is thin (1.6 mm). Additional Load When adding loads by USB power supply, the maximum operational current is 300 mA at 3.3 V, current is 100 mA at 5 V operation. -
Page 23: Code Development
Target Board for RX23W Code Development Code Development Figure 8-1 shows the setting of e2 studio when creating a new project for the Target Board for RX23W. Debug hardware: Select [E2 Lite (RX)]. Power supply from the emulator: Select [No]. Figure 8-1: e2 studio settings (Note) Do not connect another Target Board to your PC while connecting the Target Board for RX23W. -
Page 24: Additional Information
Copyright This document may be, wholly or partially, subject to change without notice. All rights reserved. Duplication of this document, either in whole or part is prohibited without the written permission of Renesas Electronics Europe Limited. © 2019 Renesas Electronics Corporation. All rights reserved. -
Page 25: Appendix A. Conformity Assessment
Target Board for RX23W Appendix A. Conformity Assessment Appendix A. Conformity Assessment Target Board for RX23W conforms to the laws and regulations that are described in the following. FCC/ISED Regulatory Since this module is not sold to general end users directly, there is no user manual of module. For the details about this module, please refer to the specification sheet of module. - Page 26 ≤-30 dBm / 1 MHz (其它 1 - 12.75 GHz) 2.不得擅自更改发射频率、加大发射功率(包括额外加装射频功率放大器)，不得擅自外接天线或改用其它发射 天线； 3.使用时不得对各种合法的无线电通信业务产生有害干扰；一旦发现有干扰现象时，应立即停止使用，并采取 措施消除干扰后方可继续使用； 4.使用微功率无线电设备，必须忍受各种无线电业务的干扰或工业、科学及医疗应用设备的辐射干扰； 5.不得在飞机和机场附近使用。 RE Directive Hereby, Renesas Electronics Corporation declares that the radio equipment type RTK0EN0001D01001BZ is in compliance with Directive 2014/53/EU. R01UHxxxEG0100 Rev.0.60 Page 26 of 28 26, 2019...
- Page 27 Target Board for RX23W User’s Manual REVISION HISTORY Description Rev. Date Page Summary 0.10 Oct.03.2019 First Edition issued Fixed ISED 0.60 Nov. 26, 2019 R01UHxxxEG0100 Rev.0.60 Page 27 of 28 26, 2019...
- Page 28 RX23W Group Target Board for RX23W User’s Manual Publication Date: Rev. 0.60 26, 2019 Published by: Renesas Electronics Corporation...
