Burkert 2060 Quick Start Manual
2/2-way angle seat valve, 2/2-way globe valve
Hide thumbs
Also See for 2060:
- Quick start manual (46 pages) ,
- Operating instructions manual (31 pages) ,
- Installation instructions manual (28 pages)
Subscribe to Our Youtube Channel
Related Manuals for Burkert 2060
Summary of Contents for Burkert 2060
- Page 1 Type 2060/2061 2/2-way Angle Seat Valve, 2/2-way Globe valve 2/2-Wege-Schrägsitzventil, 2/2-Wege Geradsitzventil Vanne à siège incliné 2/2 voies, Vanne à siège droit 2/2 voies Quickstart English Deutsch Français...
- Page 2 We reserve the right to make technical changes without notice. Technische Änderungen vorbehalten. Sous réserve de modifications techniques. © 2016 Bürkert Werke GmbH Operating Instructions 1604/00_EU-ML_00810476/ Original DE...
-
Page 3: Table Of Contents
The operating instructions can be found on the Internet at: 10 REMOVAL ...................... 16 www.burkert.com 11 PACKAGING, TRANSPORT, STORAGE .......... 16 Definition of term / abbreviation The term “device” used in these instructions always stands for the angle seat valve Type 2060 or globe valve 2061. english... -
Page 4: Symbols
Type 2060/2061 Symbols SYMBOLS AUTHORIZED USE DANGER! Non-authorized use of the angle seat valve Type 2100 may be a hazard to people, nearby equipment and the environment. Warns of an immediate danger. ▶ The device is designed for the controlled flow of liquid and ▶ Failure to observe the warning may result in a fatal or serious injury. gaseous media. ▶ The admissible data, the operating conditions and conditions... -
Page 5: Basic Safety Instructions
Type 2060/2061 Basic safety instructions BASIC SAFETY INSTRUCTIONS Risk of injury caused by the spring jumping out when the actuator is opened. These safety instructions do not make allowance for any ▶ The actuator must not be opened. • contingencies and events which may arise during the installation, General hazardous situations. operation and maintenance of the devices. -
Page 6: General Information
Type 2060/2061 General information GENERAL INFORMATION TECHNICAL DATA Contact address Conformity Germany Type 2060/2061 conforms with the EC Directives according to the EC Declaration of Conformity (if applicable) . Bürkert Fluid Control Systems Sales Center Standards Chr.-Bürkert-Str. 13-17 D-74653 Ingelfingen The applied standards, which verify conformity with the EC Direc- Tel. - Page 7 Environment Type / Flow size material (for PTFE seal) Control function (SF) / 2060 A 25,0 PTFE VA ø 50 mm Orifice of the body / SA44 Pmed 16bar -10 – +185 °C 0 – +80 °C Sealing material / ø...
- Page 8 Type 2060/2061 Technical data Minimum pilot pressure: flow direction below the seat General technical data (medium flow against the closing direction of the valve) Media Required minimum pilot pressure P with control function A: Control medium Neutral gases, air Actuator size [mm] Flow media Water, alcohol, fuel, hydraulic liquids,...
-
Page 9: Installation
Type 2060/2061 Installation INSTALLATION Before installation • The angle seat valve can be installed in any installation position, Safety instructions preferably with the actuator face up. DANGER! • Before connecting the valve, ensure the lines are flush. • Observe direction of flow (see type label). - Page 10 Type 2060/2061 Installation Installation Transparent cap Pilot air port CFB, CFI WARNING! with position Air discharge connection indicator Risk of injury from improper assembly! Actuator Assembly with unsuitable tools or non-observance of the tight- ening torque is dangerous as the device may be damaged. Pilot air port CFA, CFI Nipple ▶...
- Page 11 Type 2060/2061 Installation → 7.3.2 Install actuator (welded body) Screw actuator into the valve body. Observe tightening torque (see “Tab. 5”). Pilot air port CFB, CFI Graphite seal Air discharge connection CFA Fig. 3: Graphite seal Pilot air port CFA, CFI →...
- Page 12 Type 2060/2061 Installation 7.3.4 Rotating the actuator Open-end wrench The position of the connections can be aligned steplessly by rotating the actuator through 360°. NOTE! Damage to the seat seal or the seat contour. ▶ When rotating the actuator, ensure that the valve is in open position. Procedure: →...
- Page 13 Type 2060/2061 Installation Pneumatic connection Control functions A and B: → Connect the control medium to the pilot air port 1 of the actuator. DANGER! Silencer Risk of injury from high pressure! For the versions with a plug-in connection the silencer for reducing ▶ Before loosening the lines and valves, turn off the pressure and the exhaust air noise is supplied loose.
-
Page 14: Start-Up
Type 2060/2061 Start-up START-UP Flow direction 8.3.1 Angle seat valve Safety instructions WARNING! Risk of injury from improper operation! Improper operation may result in injuries as well as damage to the device and the area around it. ▶ Before start-up, ensure that the operating personnel are familiar... -
Page 15: Maintenance Work
Type 2060/2061 Maintenance work MAINTENANCE WORK 8.3.3 Flow direction above the seat → Control function A, CFA: closes by spring force against the medium Complete a visual inspection of the equipment once a year. Shorter flow. Control function B, CFB: closes with the control pressure against maintenance intervals may be recommended depending on the the medium flow. -
Page 16: Removal
Type 2060/2061 Removal REMOVAL PACKAGING, TRANSPORT, STORAGE DANGER! NOTE! Risk of injury from discharge of medium and pressure! Transport and storage damage! It is dangerous to remove a device which is under pressure due to ▶ Protect the device against moisture and dirt in shock-resistant the sudden release of pressure or discharge of medium. - Page 17 www.burkert.com...
